Test Date: 2016-04-25 11:13
Analysis date: 2016-05-26 16:19
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
46.853375 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
46.853375 |
|
| medianSlope |
median Slope |
47.0315 |
|
| minSlope |
min Slope |
42.983 |
|
| maxSlope |
max Slope |
50.196 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-36.8655 |
|
| medianOffset |
median Offset |
-33.2 |
|
| minOffset |
min Offset |
-199.195 |
|
| maxOffset |
max Offset |
85.779 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.288375 |
|
| medianchi2 |
median chi2 |
1.2125 |
|
| minchi2 |
min chi2 |
0.034 |
|
| maxchi2 |
max chi2 |
9.338 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
48.5 e- / Vcal
|
0.2 e- / Vcal
|
85.8 e-
|
18.0 e-
|
|
1
|
48.8 e- / Vcal
|
0.1 e- / Vcal
|
-81.2 e-
|
6.5 e-
|
|
2
|
45.2 e- / Vcal
|
0.2 e- / Vcal
|
70.5 e-
|
19.6 e-
|
|
3
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-112.4 e-
|
6.0 e-
|
|
4
|
46.7 e- / Vcal
|
0.1 e- / Vcal
|
-69.3 e-
|
18.2 e-
|
|
5
|
45.4 e- / Vcal
|
0.1 e- / Vcal
|
-171.0 e-
|
6.1 e-
|
|
6
|
47.2 e- / Vcal
|
0.1 e- / Vcal
|
-199.2 e-
|
17.0 e-
|
|
7
|
47.5 e- / Vcal
|
0.1 e- / Vcal
|
47.1 e-
|
16.4 e-
|
|
8
|
45.3 e- / Vcal
|
0.1 e- / Vcal
|
-172.5 e-
|
18.5 e-
|
|
9
|
50.2 e- / Vcal
|
0.1 e- / Vcal
|
2.9 e-
|
6.7 e-
|
|
10
|
44.0 e- / Vcal
|
0.1 e- / Vcal
|
18.5 e-
|
6.5 e-
|
|
11
|
43.0 e- / Vcal
|
0.1 e- / Vcal
|
50.9 e-
|
7.6 e-
|
|
12
|
46.9 e- / Vcal
|
0.1 e- / Vcal
|
63.6 e-
|
17.8 e-
|
|
13
|
48.4 e- / Vcal
|
0.2 e- / Vcal
|
50.2 e-
|
21.1 e-
|
|
14
|
48.7 e- / Vcal
|
0.1 e- / Vcal
|
-81.7 e-
|
17.2 e-
|
|
15
|
48.6 e- / Vcal
|
0.2 e- / Vcal
|
-92.1 e-
|
21.1 e-
|
|
Average
|
46.9 e- / Vcal
|
|
-36.9 e-
|
|
|
Median
|
92.9 e- / Vcal
|
|
-125.4 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
