Test Date: 2016-04-25 11:13
Analysis date: 2016-05-26 16:19
Chip 15
X-ray Calibration - Target Zn Method Spectrum Chip C15
Plot
Center Center of Peak 49.46 ± 0.09 Vcal
TargetEnergy Energy of target Zn 8638.91 eV
TargetNElectrons Energy of target Zn 2399.7 nElectrons
Chi2PerNDF Chi^2 per NDF 2.49
Rate Rate 239.10 kHz/cm²
X-ray Calibration - Target Mo Method Spectrum Chip C15
Plot
Center Center of Peak 101.73 ± 0.09 Vcal
TargetEnergy Energy of target Mo 17479.37 eV
TargetNElectrons Energy of target Mo 4855.38 nElectrons
Chi2PerNDF Chi^2 per NDF 2.81
Rate Rate 378.50 kHz/cm²
X-ray Calibration - Target Ag Method Spectrum Chip C15
Plot
Center Center of Peak 128.45 ± 0.12 Vcal
TargetEnergy Energy of target Ag 22162.92 eV
TargetNElectrons Energy of target Ag 6156.37 nElectrons
Chi2PerNDF Chi^2 per NDF 3.75
Rate Rate 216.60 kHz/cm²
X-ray Calibration - Target Sn Method Spectrum Chip C15
Plot
Center Center of Peak 146.25 ± 0.15 Vcal
TargetEnergy Energy of target Sn 25271.36 eV
TargetNElectrons Energy of target Sn 7019.82 nElectrons
Chi2PerNDF Chi^2 per NDF 3.65
Rate Rate 142.90 kHz/cm²
X-ray Calibration - Vcal Calibration Method Spectrum Chip C15
Plot
Slope Slope 48.636 ± 0.177 nElectrons/VCal
Offset Offset -92.104 ± 21.069 nElectrons
X-ray Hit Map - Target Zn Method Spectrum Chip C15
Plot
Rate Rate 239.10 kHz/cm²
NTrigs N Trig 5914676 Trigger
NHits N Hits 22064 Hits
X-ray Hit Map - Target Mo Method Spectrum Chip C15
Plot
Rate Rate 378.50 kHz/cm²
NTrigs N Trig 5914603 Trigger
NHits N Hits 34927 Hits
X-ray Hit Map - Target Ag Method Spectrum Chip C15
Plot
Rate Rate 216.60 kHz/cm²
NTrigs N Trig 5915030 Trigger
NHits N Hits 19988 Hits
X-ray Hit Map - Target Sn Method Spectrum Chip C15
Plot
Rate Rate 142.90 kHz/cm²
NTrigs N Trig 5914572 Trigger
NHits N Hits 13189 Hits
