Test Date: 2016-04-25 11:13
Analysis date: 2016-05-26 16:19
Chip 6
X-ray Calibration - Target Zn Method Spectrum Chip C6
Plot
Center Center of Peak 54.09 ± 0.07 Vcal
TargetEnergy Energy of target Zn 8638.91 eV
TargetNElectrons Energy of target Zn 2399.7 nElectrons
Chi2PerNDF Chi^2 per NDF 1.29
Rate Rate 288.30 kHz/cm²
X-ray Calibration - Target Mo Method Spectrum Chip C6
Plot
Center Center of Peak 107.05 ± 0.07 Vcal
TargetEnergy Energy of target Mo 17479.37 eV
TargetNElectrons Energy of target Mo 4855.38 nElectrons
Chi2PerNDF Chi^2 per NDF 2.66
Rate Rate 435.90 kHz/cm²
X-ray Calibration - Target Ag Method Spectrum Chip C6
Plot
Center Center of Peak 134.79 ± 0.1 Vcal
TargetEnergy Energy of target Ag 22162.92 eV
TargetNElectrons Energy of target Ag 6156.37 nElectrons
Chi2PerNDF Chi^2 per NDF 4.69
Rate Rate 230.90 kHz/cm²
X-ray Calibration - Target Sn Method Spectrum Chip C6
Plot
Center Center of Peak 152.78 ± 0.13 Vcal
TargetEnergy Energy of target Sn 25271.36 eV
TargetNElectrons Energy of target Sn 7019.82 nElectrons
Chi2PerNDF Chi^2 per NDF 4.11
Rate Rate 144.80 kHz/cm²
X-ray Calibration - Vcal Calibration Method Spectrum Chip C6
Plot
Slope Slope 47.204 ± 0.137 nElectrons/VCal
Offset Offset -199.195 ± 16.956 nElectrons
X-ray Hit Map - Target Zn Method Spectrum Chip C6
Plot
Rate Rate 288.30 kHz/cm²
NTrigs N Trig 5914676 Trigger
NHits N Hits 26597 Hits
X-ray Hit Map - Target Mo Method Spectrum Chip C6
Plot
Rate Rate 435.90 kHz/cm²
NTrigs N Trig 5914603 Trigger
NHits N Hits 40218 Hits
X-ray Hit Map - Target Ag Method Spectrum Chip C6
Plot
Rate Rate 230.90 kHz/cm²
NTrigs N Trig 5915030 Trigger
NHits N Hits 21306 Hits
X-ray Hit Map - Target Sn Method Spectrum Chip C6
Plot
Rate Rate 144.80 kHz/cm²
NTrigs N Trig 5914572 Trigger
NHits N Hits 13360 Hits
