Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Analysis date: 2019-05-03 15:24
M1506 XRayHRQualification
Summary
| Module | Module | M1506 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 0/0/16 | |
| PixelDefects | Total Pixel Defects | 15455 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 10073 | |
| HotPixelDefects | Hot Pixels | 8320 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 7 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 9 | |
| Efficiency | Efficiency 50/120 | 87.28/87.20 | % |
| Noise | Mean Noise | 358 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
4160 | 26 | # | # | # | 0.0 | 0 | 0.0 | 0/0 | 52 | -7737981893990387647729455686024807636895839651402580770967127295387957590526272055192490212857071697298347097360926753628519365552856072210874368 | 703 | 1469 |
|
Chip 1
|
C
|
201 | 0 | 99.89 | 99.79 | 0.22 | 231.9 | 0 | 78.5 | 89/89 | 0+3542/0 | 2200 | 252 | 201 |
|
Chip 2
|
C
|
369 | 0 | 99.90 | 99.83 | 0.19 | 241.8 | 0 | 75.2 | 0/0 | 0 | 10738 | 297 | 369 |
|
Chip 3
|
C
|
531 | 0 | 99.89 | 99.80 | 0.25 | 185.0 | 0 | 59.4 | 0/0 | 0 | 888 | 324 | 531 |
|
Chip 4
|
C
|
399 | 0 | 99.88 | 99.78 | 0.22 | 170.7 | 0 | 57.2 | 62/62 | 0+1737/0 | 1230 | 311 | 399 |
|
Chip 5
|
C
|
525 | 0 | 99.89 | 99.80 | 0.14 | 246.0 | 0 | 81.0 | 64/64 | 0+2815/0 | 1025 | 304 | 525 |
|
Chip 6
|
C
|
745 | 0 | 99.90 | 99.81 | 0.25 | 288.6 | 0 | 89.0 | 0/0 | 0 | 1492 | 330 | 745 |
|
Chip 7
|
C
|
4160 | 26 | # | # | # | 0.0 | 0 | 0.0 | 0/0 | 52 | -7737981893990387647729455686024807636895839651402580770967127295387957590526272055192490212857071697298347097360926753628519365552856072210874368 | 703 | 1469 |
|
Chip 8
|
C
|
710 | 0 | 99.91 | 99.81 | 0.21 | 281.6 | 0 | 96.8 | 764/764 | 0+4969/0 | 1440 | 331 | 710 |
|
Chip 9
|
C
|
1123 | 0 | 99.90 | 99.80 | 0.13 | 316.8 | 0 | 107.0 | 884/884 | 0+4996/0 | 1267 | 352 | 1123 |
|
Chip 10
|
C
|
608 | 0 | 99.90 | 99.80 | 0.2 | 258.9 | 0 | 80.4 | 0/0 | 0 | 1144 | 322 | 608 |
|
Chip 11
|
C
|
375 | 0 | 99.89 | 99.79 | 0.28 | 202.4 | 0 | 63.2 | 0/0 | 0 | 692 | 298 | 375 |
|
Chip 12
|
C
|
210 | 0 | 99.91 | 99.81 | 0.18 | 159.4 | 0 | 54.8 | 85/85 | 0+1462/0 | 1316 | 295 | 210 |
|
Chip 13
|
C
|
327 | 0 | 99.89 | 99.80 | 0.14 | 231.7 | 0 | 77.7 | 127/127 | 0+4014/0 | 1219 | 289 | 327 |
|
Chip 14
|
C
|
492 | 0 | 99.91 | 99.79 | 0.22 | 273.4 | 0 | 84.2 | 0/0 | 0 | 893 | 293 | 492 |
|
Chip 15
|
C
|
520 | 0 | 99.89 | 99.79 | 0.27 | 279.8 | 0 | 87.4 | 0/0 | 0 | 1504 | 317 | 520 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2019-05-03 | |
| TestTime | Test Time | 10:27 | |
| TestDuration | Duration | 0:14:10 | |
| pXar | pXar version | v2.7.6+78~ge523427 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 440 | |
| nWarnings | # Warnings | 66 | |
| channel_0_count | Channel 0 | 21 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 24 | |
| channel_3_count | Channel 3 | 3 | |
| message_eventid_count | Event ID mismatch | 32 | |
| message_readback_count | Readback start marker | 62 |
MoReWeb-v1.1.0
on branch AnalyzeNewXPixelAlive
