Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Analysis date: 2019-05-03 15:24
Chip 9
Grading
| ROCGrade | Final ROC Grade | C | |
| NumberOfHotPixels | # Hot Pixels 300/100 | 0/0 | |
| NumberOfNonUniformColumns | # Non-Uniform Columns 300/100 | 0 | |
| NumberOfNonUniformEvents | # Non-Uniform ROC Events 300/100 | 884/0 | |
| NumberOfNonUniformColumnEvents | # Non-Uniform Col. Events 300/100 | 4996/0 | |
| BadDoubleColumns | # Bad Double Columns | 0 | |
| BumpBondingDefects | # Bump Bonding Defects 300/100 | 0/0 | |
| Efficiency | Efficiency 50/120 | 99.9/99.8 | |
| EfficiencyFit | Efficiency Fit | chi2/ndf: 0.13, # points: 52 | |
| EfficiencyGrade | Efficiency Grade 50/120 | (A)/A | |
| BadDoubleColumnsGrade | Bad DC Grade | A | |
| HotPixelsGrade | Hot Pixels Grade 300/100 | A/A | |
| HitMapGrade | Hit Map Grade 300/100 | A/A | |
| ReadoutUniformityOverTimeGrade | ROC Read. Unif. Grade 300/100 | C/A | |
| ColumnReadoutUniformityOverTimeGrade | Column Read. Unif. Grade 300/100 | C/A | |
| ColumnUniformityGrade | Column Uniformity Grade | A | |
| NoiseGrade | Noise Grade | B |
Efficiency Interpolation: C9
| fitfunction | Fit | [0]-[1]*x^3 | |
| BadDoubleColumns | # Bad DCs (excluded from fit) | 0 | |
| Chi2NDF | chi2/ndf | 0.13 | |
| NumberFitPoints | # fit points | 52 | |
| p0 | p0 | 99.91 | |
| p1 | p1 | 6.48e-08 | |
| InterpolatedEfficiency50 | Interpol. Efficiency 50 | 99.90 | |
| InterpolatedEfficiency120 | Interpol. Efficiency 120 | 99.80 |
Hit Map 300: C9
| RealHitrate | Real Hitrate | 316.79 | MHz/cm2 |
| NumberOfDefectivePixels | # Defective Pixels | 0 |
Hit Map 100: C9
| RealHitrate | Real Hitrate | 107.00 | MHz/cm2 |
| NumberOfDefectivePixels | # Defective Pixels | 0 |
Col. Read. Unif. 300: C9
Col. Read. Unif. 100: C9
Read. Unif. over Time 300: C9
Time unif. distribution 300: C9
| chi2/ndf | chi2/ndf | 90.68 | |
| sigma | σ | 3445.02 | |
| sigma_th | σ_th | 101.94 | |
| expectation | Red curve (expected) | Poisson |
Read. Unif. over Time 100: C9
Time unif. distribution 100: C9
| chi2/ndf | chi2/ndf | 1.22 | |
| sigma | σ | 64.25 | |
| sigma_th | σ_th | 59.25 | |
| expectation | Red curve (expected) | Poisson |
Col. Uniformity per Event: C9 300
| mu | μ | 25.58 | |
| sigma | fit error of μ | 2.14 | |
| NumberOfNonUniformColumnEvents | Non uniform 10.000 event bins | 4996 |
Col. Uniformity per Event: C9 100
| mu | μ | 25.58 | |
| sigma | fit error of μ | 2.13 | |
| NumberOfNonUniformColumnEvents | Non uniform 10.000 event bins | 0 |
S-Curve widths: Noise (e^{-}) C9 250
| N | N | 3898 | |
| mu | μ | 351.91 | |
| sigma | RMS | 150.41 | |
| threshold | thr | 1267.06 | |
| fit | fit | Gaussian | |
| fit_peak | μ fit | 320.55 | |
| fit_sigma | σ fit | 94.34 | |
| MeasuredHitrate | Measured hitrate: | 74.4 | |
| under | <= | 156.00 | |
| over | >= | 106.00 |
DC Efficiency Distribution: C9
| MeanEfficiency_50 | Mean Efficiency 50 MHz/cm2 | 99.90 | |
| MeanEfficiency_120 | Mean Efficiency 120 MHz/cm2 | 99.78 | |
| NBadDoubleColumns | Bad Double Columns | 0 |
