Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Chip 13
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 300/100 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 300/100 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 300/100 127/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 300/100 4014/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 300/100 0/0
Efficiency Efficiency 50/120 99.89/99.8
EfficiencyFit Efficiency Fit chi2/ndf: 0.14, # points: 61
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 300/100 A/A
HitMapGrade Hit Map Grade 300/100 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 300/100 C/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 300/100 C/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C13
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.14
NumberFitPoints # fit points 61
p0 p0 99.90
p1 p1 5.71e-08
InterpolatedEfficiency50 Interpol. Efficiency 50 99.89
InterpolatedEfficiency120 Interpol. Efficiency 120 99.80
Efficiency Map 50: C13
Efficiency Map 100: C13
Efficiency Map 150: C13
Efficiency Map 200: C13
Efficiency Map 250: C13
Efficiency Map 300: C13
Efficiency Map 400: C13
Efficiency Distr. 50: C13
Plot
N N 4160
mu μ 99.93
sigma σ 0.38
Efficiency Distr. 100: C13
Plot
N N 4160
mu μ 99.85
sigma σ 0.55
Efficiency Distr. 150: C13
Plot
N N 4160
mu μ 99.78
sigma σ 0.67
Efficiency Distr. 200: C13
Plot
N N 4160
mu μ 99.69
sigma σ 0.78
Efficiency Distr. 250: C13
Plot
N N 4160
mu μ 99.60
sigma σ 0.91
Efficiency Distr. 300: C13
Plot
N N 4160
mu μ 99.50
sigma σ 1.02
Efficiency Distr. 400: C13
Plot
N N 4160
mu μ 99.35
sigma σ 1.18
Background Map 50: C13
Plot
RealHitrate Real Hitrate 39.17 MHz/cm2
Background Map 100: C13
Plot
RealHitrate Real Hitrate 80.15 MHz/cm2
Background Map 150: C13
Plot
RealHitrate Real Hitrate 122.37 MHz/cm2
Background Map 200: C13
Plot
RealHitrate Real Hitrate 165.85 MHz/cm2
Background Map 250: C13
Plot
RealHitrate Real Hitrate 210.72 MHz/cm2
Background Map 300: C13
Plot
RealHitrate Real Hitrate 254.55 MHz/cm2
Background Map 400: C13
Plot
RealHitrate Real Hitrate 314.61 MHz/cm2
Retrim Hot Pix 150: C13
Retrim Hot Pix 50: C13
Masked Hot Pixels 300: C13
Masked Hot Pixels 100: C13
Hit Map 300: C13
Plot
RealHitrate Real Hitrate 231.67 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 300: C13
Hit Map 100: C13
Plot
RealHitrate Real Hitrate 77.72 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 100: C13
Col. Read. Unif. 300: C13
Plot
N N 6711812
mu μ 144058
sigma σ 28358.12
Col. Read. Unif. 100: C13
Plot
N N 2256858
mu μ 48340
sigma σ 9044.72
Read. Unif. over Time 300: C13
Plot
N N 7490997
mu μ 7597
sigma_th σ_th 87.16
Time unif. distribution 300: C13
Plot
chi2/ndf chi2/ndf 76.73
sigma σ 2250.60
sigma_th σ_th 87.17
expectation Red curve (expected) Poisson
Read. Unif. over Time 100: C13
Plot
N N 2513680
mu μ 2549
sigma_th σ_th 50.49
Time unif. distribution 100: C13
Plot
chi2/ndf chi2/ndf 1.07
sigma σ 53.88
sigma_th σ_th 50.49
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C13
Col. Uniformity per Event: C13 300
Plot
mu μ 24.21
sigma fit error of μ 2.18
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 4014
Col. Uniformity per Event: C13 100
Plot
mu μ 23.69
sigma fit error of μ 2.16
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C13 250
Plot
N N 3952
mu μ 289.43
sigma RMS 106.76
threshold thr 1219.21
fit fit Gaussian
fit_peak μ fit 277.08
fit_sigma σ fit 62.98
MeasuredHitrate Measured hitrate: 74.4
under <= 153.00
over >= 55.00
Alive Map: C13
DC Efficiency Distribution: C13
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.91
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.79
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C13
