Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
Chip 4
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 300/100 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 300/100 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 300/100 62/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 300/100 1737/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 300/100 0/0
Efficiency Efficiency 50/120 99.88/99.78
EfficiencyFit Efficiency Fit chi2/ndf: 0.22, # points: 84
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 300/100 A/A
HitMapGrade Hit Map Grade 300/100 A/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 300/100 C/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 300/100 C/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade B
Efficiency Interpolation: C4
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.22
NumberFitPoints # fit points 84
p0 p0 99.88
p1 p1 6.18e-08
InterpolatedEfficiency50 Interpol. Efficiency 50 99.88
InterpolatedEfficiency120 Interpol. Efficiency 120 99.78
Efficiency Map 50: C4
Efficiency Map 100: C4
Efficiency Map 150: C4
Efficiency Map 200: C4
Efficiency Map 250: C4
Efficiency Map 300: C4
Efficiency Map 400: C4
Efficiency Distr. 50: C4
Plot
N N 4160
mu μ 99.95
sigma σ 0.33
Efficiency Distr. 100: C4
Plot
N N 4160
mu μ 99.88
sigma σ 0.48
Efficiency Distr. 150: C4
Plot
N N 4160
mu μ 99.81
sigma σ 0.61
Efficiency Distr. 200: C4
Plot
N N 4160
mu μ 99.73
sigma σ 0.73
Efficiency Distr. 250: C4
Plot
N N 4160
mu μ 99.69
sigma σ 0.79
Efficiency Distr. 300: C4
Plot
N N 4160
mu μ 99.56
sigma σ 0.95
Efficiency Distr. 400: C4
Plot
N N 4160
mu μ 99.22
sigma σ 1.53
Background Map 50: C4
Plot
RealHitrate Real Hitrate 31.05 MHz/cm2
Background Map 100: C4
Plot
RealHitrate Real Hitrate 61.57 MHz/cm2
Background Map 150: C4
Plot
RealHitrate Real Hitrate 92.75 MHz/cm2
Background Map 200: C4
Plot
RealHitrate Real Hitrate 123.79 MHz/cm2
Background Map 250: C4
Plot
RealHitrate Real Hitrate 156.02 MHz/cm2
Background Map 300: C4
Plot
RealHitrate Real Hitrate 188.20 MHz/cm2
Background Map 400: C4
Plot
RealHitrate Real Hitrate 241.93 MHz/cm2
Retrim Hot Pix 150: C4
Retrim Hot Pix 50: C4
Masked Hot Pixels 300: C4
Masked Hot Pixels 100: C4
Hit Map 300: C4
Plot
RealHitrate Real Hitrate 170.70 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 300: C4
Hit Map 100: C4
Plot
RealHitrate Real Hitrate 57.23 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 100: C4
Col. Read. Unif. 300: C4
Plot
N N 4936524
mu μ 106146
sigma σ 43096.02
Col. Read. Unif. 100: C4
Plot
N N 1658989
mu μ 35599
sigma σ 13996.09
Read. Unif. over Time 300: C4
Plot
N N 5519577
mu μ 5598
sigma_th σ_th 74.82
Time unif. distribution 300: C4
Plot
chi2/ndf chi2/ndf 847.17
sigma σ 1375.23
sigma_th σ_th 74.83
expectation Red curve (expected) Poisson
Read. Unif. over Time 100: C4
Plot
N N 1851144
mu μ 1877
sigma_th σ_th 43.33
Time unif. distribution 100: C4
Plot
chi2/ndf chi2/ndf 1.24
sigma σ 45.96
sigma_th σ_th 43.33
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C4
Col. Uniformity per Event: C4 300
Plot
mu μ 29.65
sigma fit error of μ 2.20
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 1737
Col. Uniformity per Event: C4 100
Plot
mu μ 29.83
sigma fit error of μ 2.16
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C4 250
Plot
N N 3955
mu μ 310.77
sigma RMS 102.12
threshold thr 1229.98
fit fit Gaussian
fit_peak μ fit 297.40
fit_sigma σ fit 59.76
MeasuredHitrate Measured hitrate: 74.4
under <= 162.00
over >= 43.00
Alive Map: C4
DC Efficiency Distribution: C4
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.90
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.77
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C4
