Test Date: 2015-10-07 14:47
Analysis date: 2016-05-26 06:06
Analysis date: 2016-05-26 06:06
M2114 XRayHRQualification
Summary
| Module | Module | M2114 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 9 | |
| BumpBondingDefects | Bump Bonding Defects | 6 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.24 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.85 | 99.14 | 0.84 | 71.0 | 2 | 24.1 | 0/0 | 0 | 1951 | 168 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.34 | 0.5 | 67.9 | 0 | 22.6 | 0/0 | 0 | 1939 | 161 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.23 | 1.44 | 64.7 | 0 | 21.6 | 0/0 | 0 | 1930 | 157 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.37 | 0.65 | 124.2 | 0 | 43.1 | 0/0 | 0 | 2087 | 182 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.87 | 99.29 | 0.63 | 127.7 | 0 | 44.2 | 0/0 | 0 | 2020 | 175 | 1 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.33 | 0.59 | 160.1 | 0 | 56.4 | 0/0 | 0 | 2167 | 169 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.35 | 0.6 | 146.3 | 0 | 51.1 | 0/0 | 0 | 2132 | 161 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.91 | 99.15 | 0.94 | 144.2 | 0 | 49.9 | 0/0 | 0 | 2112 | 168 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.30 | 0.6 | 144.0 | 0 | 50.4 | 0/0 | 0 | 2109 | 160 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.92 | 99.17 | 1.86 | 172.0 | 0 | 60.1 | 0/0 | 0 | 2184 | 176 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.30 | 0.66 | 157.5 | 0 | 56.4 | 0/0 | 0 | 2132 | 165 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.35 | 0.56 | 143.9 | 0 | 50.5 | 0/0 | 0 | 2170 | 169 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.05 | 0.69 | 126.0 | 0 | 44.2 | 0/0 | 0 | 2070 | 163 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.17 | 0.55 | 80.6 | 0 | 27.1 | 0/0 | 0 | 1997 | 169 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.86 | 99.06 | 0.61 | 81.6 | 1 | 27.7 | 0/0 | 0 | 1979 | 179 | 0 |
|
Chip 15
|
A
|
4 | 0 | 99.83 | 99.20 | 0.73 | 82.3 | 3 | 28.2 | 0/0 | 0 | 1927 | 178 | 1 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-10-07 | |
| TestTime | Test Time | 14:47 | |
| TestDuration | Duration | - | |
| pXar | pXar version | v2.6.0+21~ga0339e2 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 17 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
