Test Date: 2019-05-03 10:27
Analysis date: 2019-05-03 15:24
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
48.0968571429 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
48.0968571429 |
|
| medianSlope |
median Slope |
48.417 |
|
| minSlope |
min Slope |
43.025 |
|
| maxSlope |
max Slope |
51.427 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-524.0255 |
|
| medianOffset |
median Offset |
-578.289 |
|
| minOffset |
min Offset |
-761.008 |
|
| maxOffset |
max Offset |
-1 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
3.00857142857 |
|
| medianchi2 |
median chi2 |
3.0055 |
|
| minchi2 |
min chi2 |
0.002 |
|
| maxchi2 |
max chi2 |
7.476 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
-1.0 e- / Vcal
|
-1.0 e- / Vcal
|
-1.0 e-
|
-1.0 e-
|
|
1
|
50.7 e- / Vcal
|
0.2 e- / Vcal
|
-672.1 e-
|
26.8 e-
|
|
2
|
49.4 e- / Vcal
|
0.2 e- / Vcal
|
-689.6 e-
|
25.5 e-
|
|
3
|
48.6 e- / Vcal
|
0.2 e- / Vcal
|
-598.3 e-
|
24.1 e-
|
|
4
|
50.3 e- / Vcal
|
0.2 e- / Vcal
|
-628.3 e-
|
30.1 e-
|
|
5
|
48.1 e- / Vcal
|
0.2 e- / Vcal
|
-656.9 e-
|
26.8 e-
|
|
6
|
43.9 e- / Vcal
|
0.2 e- / Vcal
|
-514.4 e-
|
22.7 e-
|
|
7
|
-1.0 e- / Vcal
|
-1.0 e- / Vcal
|
-1.0 e-
|
-1.0 e-
|
|
8
|
44.3 e- / Vcal
|
0.1 e- / Vcal
|
-451.3 e-
|
20.1 e-
|
|
9
|
43.0 e- / Vcal
|
0.2 e- / Vcal
|
-603.6 e-
|
24.6 e-
|
|
10
|
51.4 e- / Vcal
|
0.2 e- / Vcal
|
-542.9 e-
|
24.6 e-
|
|
11
|
49.6 e- / Vcal
|
0.3 e- / Vcal
|
-761.0 e-
|
33.3 e-
|
|
12
|
51.4 e- / Vcal
|
0.2 e- / Vcal
|
-558.3 e-
|
27.6 e-
|
|
13
|
48.3 e- / Vcal
|
0.2 e- / Vcal
|
-548.9 e-
|
26.0 e-
|
|
14
|
47.1 e- / Vcal
|
0.2 e- / Vcal
|
-624.7 e-
|
24.9 e-
|
|
15
|
47.3 e- / Vcal
|
0.2 e- / Vcal
|
-532.2 e-
|
21.7 e-
|
|
Average
|
48.1 e- / Vcal
|
|
-598.7 e-
|
|
|
Median
|
42.9 e- / Vcal
|
|
-515.4 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
