Test Date: 2015-12-11 15:01
Analysis date: 2015-12-15 10:00
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
49.8013125 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
49.8013125 |
|
| medianSlope |
median Slope |
50.09 |
|
| minSlope |
min Slope |
43.038 |
|
| maxSlope |
max Slope |
53.886 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-145.3695 |
|
| medianOffset |
median Offset |
-148.7785 |
|
| minOffset |
min Offset |
-269.723 |
|
| maxOffset |
max Offset |
-20.524 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
1.45175 |
|
| medianchi2 |
median chi2 |
1.1 |
|
| minchi2 |
min chi2 |
0.013 |
|
| maxchi2 |
max chi2 |
5.095 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
49.4 e- / Vcal
|
0.1 e- / Vcal
|
-160.2 e-
|
12.6 e-
|
|
1
|
49.8 e- / Vcal
|
0.2 e- / Vcal
|
-187.7 e-
|
21.9 e-
|
|
2
|
43.0 e- / Vcal
|
0.1 e- / Vcal
|
-34.4 e-
|
14.1 e-
|
|
3
|
48.9 e- / Vcal
|
0.2 e- / Vcal
|
-232.2 e-
|
20.7 e-
|
|
4
|
53.2 e- / Vcal
|
0.2 e- / Vcal
|
-248.9 e-
|
18.1 e-
|
|
5
|
53.2 e- / Vcal
|
0.1 e- / Vcal
|
-269.7 e-
|
11.6 e-
|
|
6
|
52.1 e- / Vcal
|
0.1 e- / Vcal
|
-115.0 e-
|
11.2 e-
|
|
7
|
53.7 e- / Vcal
|
0.2 e- / Vcal
|
-176.7 e-
|
21.4 e-
|
|
8
|
53.1 e- / Vcal
|
0.2 e- / Vcal
|
-147.5 e-
|
18.9 e-
|
|
9
|
49.4 e- / Vcal
|
0.1 e- / Vcal
|
-191.4 e-
|
13.5 e-
|
|
10
|
50.4 e- / Vcal
|
0.2 e- / Vcal
|
-59.1 e-
|
17.7 e-
|
|
11
|
51.3 e- / Vcal
|
0.1 e- / Vcal
|
-147.6 e-
|
11.4 e-
|
|
12
|
53.9 e- / Vcal
|
0.1 e- / Vcal
|
-123.7 e-
|
10.3 e-
|
|
13
|
46.8 e- / Vcal
|
0.2 e- / Vcal
|
-20.5 e-
|
21.0 e-
|
|
14
|
43.5 e- / Vcal
|
0.2 e- / Vcal
|
-149.9 e-
|
21.6 e-
|
|
15
|
45.2 e- / Vcal
|
0.1 e- / Vcal
|
-61.2 e-
|
11.4 e-
|
|
Average
|
49.8 e- / Vcal
|
|
-145.4 e-
|
|
|
Median
|
106.8 e- / Vcal
|
|
-324.2 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
