Test Date: 2016-08-03 11:22
Analysis date: 2016-08-04 09:48
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
45.812125 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
45.812125 |
|
| medianSlope |
median Slope |
46.069 |
|
| minSlope |
min Slope |
40.757 |
|
| maxSlope |
max Slope |
50.045 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-43.526625 |
|
| medianOffset |
median Offset |
-45.0455 |
|
| minOffset |
min Offset |
-156.773 |
|
| maxOffset |
max Offset |
82.756 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
3.4916 |
|
| medianchi2 |
median chi2 |
1.332 |
|
| minchi2 |
min chi2 |
0.005 |
|
| maxchi2 |
max chi2 |
34.42 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
48.4 e- / Vcal
|
0.1 e- / Vcal
|
-71.6 e-
|
7.2 e-
|
|
1
|
45.9 e- / Vcal
|
0.1 e- / Vcal
|
37.1 e-
|
17.1 e-
|
|
2
|
47.4 e- / Vcal
|
0.2 e- / Vcal
|
-117.0 e-
|
20.1 e-
|
|
3
|
46.2 e- / Vcal
|
0.1 e- / Vcal
|
-102.8 e-
|
15.7 e-
|
|
4
|
44.0 e- / Vcal
|
0.1 e- / Vcal
|
82.8 e-
|
6.3 e-
|
|
5
|
42.1 e- / Vcal
|
0.1 e- / Vcal
|
61.9 e-
|
19.8 e-
|
|
6
|
40.8 e- / Vcal
|
0.1 e- / Vcal
|
-82.0 e-
|
15.3 e-
|
|
7
|
43.0 e- / Vcal
|
0.1 e- / Vcal
|
-8.6 e-
|
17.1 e-
|
|
8
|
46.5 e- / Vcal
|
0.1 e- / Vcal
|
-113.1 e-
|
6.1 e-
|
|
9
|
47.2 e- / Vcal
|
0.1 e- / Vcal
|
-156.8 e-
|
6.4 e-
|
|
10
|
45.7 e- / Vcal
|
0.1 e- / Vcal
|
10.2 e-
|
5.4 e-
|
|
11
|
47.3 e- / Vcal
|
0.1 e- / Vcal
|
7.8 e-
|
14.7 e-
|
|
12
|
47.0 e- / Vcal
|
0.1 e- / Vcal
|
-128.9 e-
|
14.8 e-
|
|
13
|
50.0 e- / Vcal
|
0.2 e- / Vcal
|
-27.8 e-
|
18.8 e-
|
|
14
|
45.8 e- / Vcal
|
0.1 e- / Vcal
|
-62.3 e-
|
6.9 e-
|
|
15
|
45.7 e- / Vcal
|
0.1 e- / Vcal
|
-25.3 e-
|
6.8 e-
|
|
Average
|
45.8 e- / Vcal
|
|
-43.5 e-
|
|
|
Median
|
89.4 e- / Vcal
|
|
-121.7 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
