Test Date: 2016-04-11 17:49
Analysis date: 2016-05-26 13:55
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
46.9120625 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
46.9120625 |
|
| medianSlope |
median Slope |
46.904 |
|
| minSlope |
min Slope |
45.014 |
|
| maxSlope |
max Slope |
49.409 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-82.8241875 |
|
| medianOffset |
median Offset |
-94.5095 |
|
| minOffset |
min Offset |
-217.012 |
|
| maxOffset |
max Offset |
182.063 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.2861875 |
|
| medianchi2 |
median chi2 |
0.8575 |
|
| minchi2 |
min chi2 |
0.032 |
|
| maxchi2 |
max chi2 |
15.546 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
47.0 e- / Vcal
|
0.2 e- / Vcal
|
-85.2 e-
|
20.3 e-
|
|
1
|
47.4 e- / Vcal
|
0.1 e- / Vcal
|
-83.2 e-
|
8.6 e-
|
|
2
|
45.6 e- / Vcal
|
0.2 e- / Vcal
|
182.1 e-
|
24.6 e-
|
|
3
|
46.9 e- / Vcal
|
0.2 e- / Vcal
|
-86.1 e-
|
18.5 e-
|
|
4
|
45.5 e- / Vcal
|
0.1 e- / Vcal
|
-95.2 e-
|
6.9 e-
|
|
5
|
49.4 e- / Vcal
|
0.1 e- / Vcal
|
43.7 e-
|
15.7 e-
|
|
6
|
45.8 e- / Vcal
|
0.1 e- / Vcal
|
-93.8 e-
|
18.5 e-
|
|
7
|
46.8 e- / Vcal
|
0.2 e- / Vcal
|
-138.0 e-
|
20.3 e-
|
|
8
|
46.3 e- / Vcal
|
0.2 e- / Vcal
|
-217.0 e-
|
19.1 e-
|
|
9
|
46.9 e- / Vcal
|
0.1 e- / Vcal
|
-117.0 e-
|
16.6 e-
|
|
10
|
46.6 e- / Vcal
|
0.1 e- / Vcal
|
-183.7 e-
|
5.8 e-
|
|
11
|
48.7 e- / Vcal
|
0.2 e- / Vcal
|
-45.5 e-
|
17.5 e-
|
|
12
|
47.2 e- / Vcal
|
0.2 e- / Vcal
|
-209.5 e-
|
19.4 e-
|
|
13
|
45.0 e- / Vcal
|
0.2 e- / Vcal
|
129.1 e-
|
21.8 e-
|
|
14
|
46.9 e- / Vcal
|
0.2 e- / Vcal
|
-160.1 e-
|
20.6 e-
|
|
15
|
48.7 e- / Vcal
|
0.2 e- / Vcal
|
-165.7 e-
|
23.2 e-
|
|
Average
|
46.9 e- / Vcal
|
|
-82.8 e-
|
|
|
Median
|
93.0 e- / Vcal
|
|
-355.1 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
