Test Date: 2016-03-29 10:42
Analysis date: 2016-05-26 13:30
Analysis date: 2016-05-26 13:30
M2190 XRayHRQualification
Summary
| Module | Module | M2190 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 114 | |
| BumpBondingDefects | Bump Bonding Defects | 111 | |
| NoisyPixels | Noisy Pixels | 3 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.25 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
B
|
52 | 0 | 99.89 | 99.35 | 0.4 | 22.8 | 68.1 | 52 | 0/0 | 0 | 1946 | 183 | 0 |
|
Chip 1
|
A
|
12 | 0 | 99.86 | 99.10 | 0.43 | 22.1 | 67.1 | 12 | 0/0 | 0 | 1950 | 163 | 0 |
|
Chip 2
|
A
|
9 | 0 | 99.87 | 99.36 | 0.33 | 20.6 | 62.9 | 8 | 0/0 | 0 | 1883 | 172 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.09 | 0.57 | 36.1 | 106.0 | 0 | 0/0 | 0 | 2051 | 169 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.89 | 99.34 | 0.54 | 39.4 | 115.9 | 0 | 0/0 | 0 | 2016 | 180 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.88 | 99.32 | 0.54 | 47.6 | 136.7 | 1 | 0/0 | 0 | 2092 | 171 | 0 |
|
Chip 6
|
A
|
1 | 0 | 99.86 | 99.34 | 0.54 | 47.0 | 136.8 | 0 | 0/0 | 0 | 2075 | 175 | 1 |
|
Chip 7
|
A
|
0 | 0 | 99.87 | 99.28 | 0.72 | 45.1 | 130.9 | 0 | 0/0 | 0 | 2091 | 172 | 0 |
|
Chip 8
|
A
|
1 | 0 | 99.88 | 99.37 | 0.42 | 47.2 | 136.6 | 1 | 0/0 | 0 | 2110 | 164 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.34 | 0.49 | 45.3 | 131.7 | 0 | 0/0 | 0 | 2098 | 165 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.41 | 0.42 | 48.2 | 139.6 | 0 | 0/0 | 0 | 2119 | 163 | 0 |
|
Chip 11
|
A
|
3 | 0 | 99.89 | 99.33 | 0.46 | 42.1 | 123.0 | 3 | 0/0 | 0 | 2086 | 170 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.89 | 99.30 | 0.37 | 37.3 | 110.3 | 0 | 0/0 | 0 | 2057 | 169 | 0 |
|
Chip 13
|
A
|
3 | 0 | 99.83 | 99.00 | 0.55 | 19.5 | 60.4 | 2 | 0/0 | 0 | 1898 | 159 | 1 |
|
Chip 14
|
A
|
6 | 0 | 99.85 | 99.04 | 0.56 | 24.8 | 74.7 | 6 | 0/0 | 0 | 1970 | 169 | 0 |
|
Chip 15
|
A
|
26 | 0 | 99.86 | 99.04 | 0.48 | 24.2 | 72.4 | 26 | 0/0 | 0 | 1961 | 175 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-03-29 | |
| TestTime | Test Time | 10:42 | |
| TestDuration | Duration | 1:24:48 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
