Test Date: 2016-02-09 11:35
Analysis date: 2016-05-26 09:51
Chip 9
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 0/0
Efficiency Efficiency 50/120 99.88/99.34
EfficiencyFit Efficiency Fit chi2/ndf: 1.70, # points: 73
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C9
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 1.70
NumberFitPoints # fit points 73
p0 p0 99.92
p1 p1 3.40e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.88
InterpolatedEfficiency120 Interpol. Efficiency 120 99.34
Efficiency Map 50: C9
Efficiency Map 75: C9
Efficiency Map 100: C9
Efficiency Map 125: C9
Efficiency Map 150: C9
Efficiency Map 200: C9
Efficiency Map 250: C9
Efficiency Distr. 50: C9
Plot
N N 4160
mu μ 99.78
sigma σ 0.74
Efficiency Distr. 75: C9
Plot
N N 4160
mu μ 99.47
sigma σ 1.27
Efficiency Distr. 100: C9
Plot
N N 4160
mu μ 98.80
sigma σ 2.03
Efficiency Distr. 125: C9
Plot
N N 4160
mu μ 97.80
sigma σ 2.99
Efficiency Distr. 150: C9
Plot
N N 4160
mu μ 96.49
sigma σ 4.33
Efficiency Distr. 200: C9
Plot
N N 4160
mu μ 91.21
sigma σ 8.04
Efficiency Distr. 250: C9
Plot
N N 4160
mu μ 84.45
sigma σ 11.71
Background Map 50: C9
Plot
RealHitrate Real Hitrate 69.49 MHz/cm2
Background Map 75: C9
Plot
RealHitrate Real Hitrate 100.50 MHz/cm2
Background Map 100: C9
Plot
RealHitrate Real Hitrate 137.33 MHz/cm2
Background Map 125: C9
Plot
RealHitrate Real Hitrate 165.39 MHz/cm2
Background Map 150: C9
Plot
RealHitrate Real Hitrate 196.53 MHz/cm2
Background Map 200: C9
Plot
RealHitrate Real Hitrate 263.96 MHz/cm2
Background Map 250: C9
Plot
RealHitrate Real Hitrate 322.88 MHz/cm2
Retrim Hot Pix 150: C9
Masked Hot Pixels 50: C9
Masked Hot Pixels 150: C9
Hit Map 50: C9
Plot
RealHitrate Real Hitrate 68.42 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C9
Hit Map 150: C9
Plot
RealHitrate Real Hitrate 195.12 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C9
Col. Read. Unif. 50: C9
Plot
N N 9624000
mu μ 212693
sigma σ 62197.48
Col. Read. Unif. 150: C9
Plot
N N 27553801
mu μ 607257
sigma σ 168840.16
Read. Unif. over Time 50: C9
Plot
N N 11060015
mu μ 11217
sigma_th σ_th 105.91
Time unif. distribution 50: C9
Plot
chi2/ndf chi2/ndf 2.34
sigma σ 113.42
sigma_th σ_th 105.93
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C9
Plot
N N 31577350
mu μ 31993
sigma_th σ_th 178.87
Time unif. distribution 150: C9
Plot
chi2/ndf chi2/ndf 27.43
sigma σ 225.79
sigma_th σ_th 178.90
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C9
Col. Uniformity per Event: C9 50
Plot
mu μ 26.30
sigma fit error of μ 2.25
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C9 150
Plot
mu μ 26.10
sigma fit error of μ 2.25
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C9 100
Plot
N N 4160
mu μ 163.13
sigma RMS 16.85
threshold thr 2236.70
fit fit Gaussian
fit_peak μ fit 162.88
fit_sigma σ fit 16.54
MeasuredHitrate Measured hitrate: 136.9
Alive Map: C9
DC Efficiency Distribution: C9
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.35
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C9
