Test Date: 2016-02-09 11:35
Analysis date: 2016-05-26 09:51
Chip 7
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 0/0
Efficiency Efficiency 50/120 99.87/99.34
EfficiencyFit Efficiency Fit chi2/ndf: 0.53, # points: 84
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C7
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.53
NumberFitPoints # fit points 84
p0 p0 99.91
p1 p1 3.31e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.87
InterpolatedEfficiency120 Interpol. Efficiency 120 99.34
Efficiency Map 50: C7
Efficiency Map 75: C7
Efficiency Map 100: C7
Efficiency Map 125: C7
Efficiency Map 150: C7
Efficiency Map 200: C7
Efficiency Map 250: C7
Efficiency Distr. 50: C7
Plot
N N 4160
mu μ 99.83
sigma σ 0.59
Efficiency Distr. 75: C7
Plot
N N 4160
mu μ 99.62
sigma σ 0.90
Efficiency Distr. 100: C7
Plot
N N 4160
mu μ 99.17
sigma σ 1.39
Efficiency Distr. 125: C7
Plot
N N 4160
mu μ 98.60
sigma σ 1.98
Efficiency Distr. 150: C7
Plot
N N 4160
mu μ 97.66
sigma σ 2.67
Efficiency Distr. 200: C7
Plot
N N 4160
mu μ 94.25
sigma σ 5.05
Efficiency Distr. 250: C7
Plot
N N 4160
mu μ 89.38
sigma σ 7.39
Background Map 50: C7
Plot
RealHitrate Real Hitrate 61.15 MHz/cm2
Background Map 75: C7
Plot
RealHitrate Real Hitrate 89.43 MHz/cm2
Background Map 100: C7
Plot
RealHitrate Real Hitrate 121.88 MHz/cm2
Background Map 125: C7
Plot
RealHitrate Real Hitrate 147.64 MHz/cm2
Background Map 150: C7
Plot
RealHitrate Real Hitrate 175.19 MHz/cm2
Background Map 200: C7
Plot
RealHitrate Real Hitrate 234.16 MHz/cm2
Background Map 250: C7
Plot
RealHitrate Real Hitrate 286.57 MHz/cm2
Retrim Hot Pix 150: C7
Masked Hot Pixels 50: C7
Masked Hot Pixels 150: C7
Hit Map 50: C7
Plot
RealHitrate Real Hitrate 59.71 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C7
Hit Map 150: C7
Plot
RealHitrate Real Hitrate 170.88 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C7
Col. Read. Unif. 50: C7
Plot
N N 8538310
mu μ 185618
sigma σ 42871.64
Col. Read. Unif. 150: C7
Plot
N N 24495864
mu μ 531803
sigma σ 117729.60
Read. Unif. over Time 50: C7
Plot
N N 9652123
mu μ 9789
sigma_th σ_th 98.94
Time unif. distribution 50: C7
Plot
chi2/ndf chi2/ndf 1.19
sigma σ 102.87
sigma_th σ_th 98.96
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C7
Plot
N N 27653734
mu μ 28018
sigma_th σ_th 167.39
Time unif. distribution 150: C7
Plot
chi2/ndf chi2/ndf 12.18
sigma σ 196.14
sigma_th σ_th 167.42
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C7
Col. Uniformity per Event: C7 50
Plot
mu μ 25.90
sigma fit error of μ 2.16
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C7 150
Plot
mu μ 25.54
sigma fit error of μ 2.16
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C7 100
Plot
N N 4160
mu μ 158.46
sigma RMS 15.58
threshold thr 2185.20
fit fit Gaussian
fit_peak μ fit 158.08
fit_sigma σ fit 14.99
MeasuredHitrate Measured hitrate: 122.2
Alive Map: C7
DC Efficiency Distribution: C7
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.35
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C7
