Test Date: 2016-02-09 11:35
Analysis date: 2016-05-26 09:51
Chip 5
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 2/2
Efficiency Efficiency 50/120 99.87/99.35
EfficiencyFit Efficiency Fit chi2/ndf: 0.89, # points: 84
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C5
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.89
NumberFitPoints # fit points 84
p0 p0 99.91
p1 p1 3.29e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.87
InterpolatedEfficiency120 Interpol. Efficiency 120 99.35
Efficiency Map 50: C5
Efficiency Map 75: C5
Efficiency Map 100: C5
Efficiency Map 125: C5
Efficiency Map 150: C5
Efficiency Map 200: C5
Efficiency Map 250: C5
Efficiency Distr. 50: C5
Plot
N N 4160
mu μ 99.81
sigma σ 0.64
Efficiency Distr. 75: C5
Plot
N N 4160
mu μ 99.56
sigma σ 1.02
Efficiency Distr. 100: C5
Plot
N N 4160
mu μ 99.04
sigma σ 1.63
Efficiency Distr. 125: C5
Plot
N N 4160
mu μ 98.40
sigma σ 2.31
Efficiency Distr. 150: C5
Plot
N N 4160
mu μ 97.41
sigma σ 3.29
Efficiency Distr. 200: C5
Plot
N N 4160
mu μ 93.65
sigma σ 6.37
Efficiency Distr. 250: C5
Plot
N N 4160
mu μ 88.45
sigma σ 9.51
Background Map 50: C5
Plot
RealHitrate Real Hitrate 65.08 MHz/cm2
Background Map 75: C5
Plot
RealHitrate Real Hitrate 94.26 MHz/cm2
Background Map 100: C5
Plot
RealHitrate Real Hitrate 126.35 MHz/cm2
Background Map 125: C5
Plot
RealHitrate Real Hitrate 153.22 MHz/cm2
Background Map 150: C5
Plot
RealHitrate Real Hitrate 179.93 MHz/cm2
Background Map 200: C5
Plot
RealHitrate Real Hitrate 242.09 MHz/cm2
Background Map 250: C5
Plot
RealHitrate Real Hitrate 294.42 MHz/cm2
Retrim Hot Pix 150: C5
Masked Hot Pixels 50: C5
Masked Hot Pixels 150: C5
Hit Map 50: C5
Plot
RealHitrate Real Hitrate 62.88 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 2
BB Defects 50: C5
Hit Map 150: C5
Plot
RealHitrate Real Hitrate 176.08 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 2
BB Defects 150: C5
Col. Read. Unif. 50: C5
Plot
N N 8848398
mu μ 195465
sigma σ 53644.51
Col. Read. Unif. 150: C5
Plot
N N 24869322
mu μ 547982
sigma σ 143862.89
Read. Unif. over Time 50: C5
Plot
N N 10164192
mu μ 10309
sigma_th σ_th 101.53
Time unif. distribution 50: C5
Plot
chi2/ndf chi2/ndf 2.54
sigma σ 108.18
sigma_th σ_th 101.55
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C5
Plot
N N 28495052
mu μ 28870
sigma_th σ_th 169.91
Time unif. distribution 150: C5
Plot
chi2/ndf chi2/ndf 52.57
sigma σ 221.57
sigma_th σ_th 169.94
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C5
Col. Uniformity per Event: C5 50
Plot
mu μ 25.89
sigma fit error of μ 2.25
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C5 150
Plot
mu μ 25.93
sigma fit error of μ 2.23
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C5 100
Plot
N N 4160
mu μ 159.77
sigma RMS 16.82
threshold thr 2233.50
fit fit Gaussian
fit_peak μ fit 159.63
fit_sigma σ fit 16.38
MeasuredHitrate Measured hitrate: 126.6
Alive Map: C5
DC Efficiency Distribution: C5
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.34
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C5
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
