Test Date: 2016-02-09 11:35
Analysis date: 2016-05-26 09:51
Chip 13
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 3/3
Efficiency Efficiency 50/120 99.88/99.39
EfficiencyFit Efficiency Fit chi2/ndf: 0.34, # points: 103
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C13
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.34
NumberFitPoints # fit points 103
p0 p0 99.91
p1 p1 3.01e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.88
InterpolatedEfficiency120 Interpol. Efficiency 120 99.39
Efficiency Map 50: C13
Efficiency Map 75: C13
Efficiency Map 100: C13
Efficiency Map 125: C13
Efficiency Map 150: C13
Efficiency Map 200: C13
Efficiency Map 250: C13
Efficiency Distr. 50: C13
Plot
N N 4160
mu μ 99.93
sigma σ 0.39
Efficiency Distr. 75: C13
Plot
N N 4160
mu μ 99.87
sigma σ 0.53
Efficiency Distr. 100: C13
Plot
N N 4160
mu μ 99.76
sigma σ 0.76
Efficiency Distr. 125: C13
Plot
N N 4160
mu μ 99.64
sigma σ 1.01
Efficiency Distr. 150: C13
Plot
N N 4160
mu μ 99.42
sigma σ 1.48
Efficiency Distr. 200: C13
Plot
N N 4160
mu μ 98.71
sigma σ 2.90
Efficiency Distr. 250: C13
Plot
N N 4160
mu μ 97.55
sigma σ 5.07
Background Map 50: C13
Plot
RealHitrate Real Hitrate 28.97 MHz/cm2
Background Map 75: C13
Plot
RealHitrate Real Hitrate 42.70 MHz/cm2
Background Map 100: C13
Plot
RealHitrate Real Hitrate 59.37 MHz/cm2
Background Map 125: C13
Plot
RealHitrate Real Hitrate 72.23 MHz/cm2
Background Map 150: C13
Plot
RealHitrate Real Hitrate 86.17 MHz/cm2
Background Map 200: C13
Plot
RealHitrate Real Hitrate 117.44 MHz/cm2
Background Map 250: C13
Plot
RealHitrate Real Hitrate 144.83 MHz/cm2
Retrim Hot Pix 150: C13
Masked Hot Pixels 50: C13
Masked Hot Pixels 150: C13
Hit Map 50: C13
Plot
RealHitrate Real Hitrate 27.60 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 3
BB Defects 50: C13
Hit Map 150: C13
Plot
RealHitrate Real Hitrate 84.07 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 3
BB Defects 150: C13
Col. Read. Unif. 50: C13
Plot
N N 3727112
mu μ 85798
sigma σ 58078.99
Col. Read. Unif. 150: C13
Plot
N N 11463210
mu μ 261643
sigma σ 157688.63
Read. Unif. over Time 50: C13
Plot
N N 4461470
mu μ 4525
sigma_th σ_th 67.27
Time unif. distribution 50: C13
Plot
chi2/ndf chi2/ndf 0.98
sigma σ 68.10
sigma_th σ_th 67.28
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C13
Plot
N N 13605457
mu μ 13785
sigma_th σ_th 117.41
Time unif. distribution 150: C13
Plot
chi2/ndf chi2/ndf 5.70
sigma σ 130.20
sigma_th σ_th 117.43
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C13
Col. Uniformity per Event: C13 50
Plot
mu μ 21.86
sigma fit error of μ 2.48
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C13 150
Plot
mu μ 22.21
sigma fit error of μ 2.45
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C13 100
Plot
N N 4160
mu μ 161.76
sigma RMS 15.14
threshold thr 2006.76
fit fit Gaussian
fit_peak μ fit 161.09
fit_sigma σ fit 14.12
MeasuredHitrate Measured hitrate: 59.1
Alive Map: C13
DC Efficiency Distribution: C13
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.89
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.37
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C13
