Test Date: 2016-02-09 11:35
Analysis date: 2016-05-26 09:51
Chip 10
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 50/150 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 50/150 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 50/150 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 50/150 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 50/150 1/1
Efficiency Efficiency 50/120 99.88/99.34
EfficiencyFit Efficiency Fit chi2/ndf: 0.73, # points: 81
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 50/150 A/A
HitMapGrade Hit Map Grade 50/150 (A)/A
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 50/150 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 50/150 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C10
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.73
NumberFitPoints # fit points 81
p0 p0 99.92
p1 p1 3.37e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.88
InterpolatedEfficiency120 Interpol. Efficiency 120 99.34
Efficiency Map 50: C10
Efficiency Map 75: C10
Efficiency Map 100: C10
Efficiency Map 125: C10
Efficiency Map 150: C10
Efficiency Map 200: C10
Efficiency Map 250: C10
Efficiency Distr. 50: C10
Plot
N N 4160
mu μ 99.79
sigma σ 0.65
Efficiency Distr. 75: C10
Plot
N N 4160
mu μ 99.51
sigma σ 1.06
Efficiency Distr. 100: C10
Plot
N N 4160
mu μ 98.93
sigma σ 1.74
Efficiency Distr. 125: C10
Plot
N N 4160
mu μ 98.16
sigma σ 2.48
Efficiency Distr. 150: C10
Plot
N N 4160
mu μ 96.94
sigma σ 3.60
Efficiency Distr. 200: C10
Plot
N N 4160
mu μ 92.73
sigma σ 6.86
Efficiency Distr. 250: C10
Plot
N N 4160
mu μ 86.79
sigma σ 10.25
Background Map 50: C10
Plot
RealHitrate Real Hitrate 66.75 MHz/cm2
Background Map 75: C10
Plot
RealHitrate Real Hitrate 96.70 MHz/cm2
Background Map 100: C10
Plot
RealHitrate Real Hitrate 131.27 MHz/cm2
Background Map 125: C10
Plot
RealHitrate Real Hitrate 157.89 MHz/cm2
Background Map 150: C10
Plot
RealHitrate Real Hitrate 186.02 MHz/cm2
Background Map 200: C10
Plot
RealHitrate Real Hitrate 248.91 MHz/cm2
Background Map 250: C10
Plot
RealHitrate Real Hitrate 305.06 MHz/cm2
Retrim Hot Pix 150: C10
Masked Hot Pixels 50: C10
Masked Hot Pixels 150: C10
Hit Map 50: C10
Plot
RealHitrate Real Hitrate 65.17 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 1
BB Defects 50: C10
Hit Map 150: C10
Plot
RealHitrate Real Hitrate 182.57 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 1
BB Defects 150: C10
Col. Read. Unif. 50: C10
Plot
N N 9186984
mu μ 202598
sigma σ 55230.93
Col. Read. Unif. 150: C10
Plot
N N 25829216
mu μ 568190
sigma σ 147920.73
Read. Unif. over Time 50: C10
Plot
N N 10535089
mu μ 10685
sigma_th σ_th 103.37
Time unif. distribution 50: C10
Plot
chi2/ndf chi2/ndf 1.90
sigma σ 106.24
sigma_th σ_th 103.39
expectation Red curve (expected) Poisson
Read. Unif. over Time 150: C10
Plot
N N 29545895
mu μ 29935
sigma_th σ_th 173.02
Time unif. distribution 150: C10
Plot
chi2/ndf chi2/ndf 15.76
sigma σ 207.26
sigma_th σ_th 173.05
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C10
Col. Uniformity per Event: C10 50
Plot
mu μ 25.65
sigma fit error of μ 2.25
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C10 150
Plot
mu μ 25.67
sigma fit error of μ 2.23
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C10 100
Plot
N N 4160
mu μ 157.13
sigma RMS 15.85
threshold thr 2220.36
fit fit Gaussian
fit_peak μ fit 156.98
fit_sigma σ fit 15.78
MeasuredHitrate Measured hitrate: 131.1
Alive Map: C10
DC Efficiency Distribution: C10
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.35
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C10
