Test Date: 2016-02-08 16:09
Analysis date: 2016-05-26 09:32
Analysis date: 2016-05-26 09:32
M2150 XRayHRQualification
Summary
| Module | Module | M2150 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 56 | |
| BumpBondingDefects | Bump Bonding Defects | 51 | |
| NoisyPixels | Noisy Pixels | 2 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.30 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.08 | 0.57 | 25.4 | 78.0 | 0 | 0/0 | 0 | 1970 | 161 | 0 |
|
Chip 1
|
A
|
8 | 0 | 99.88 | 99.36 | 0.45 | 27.9 | 85.5 | 8 | 0/0 | 0 | 2003 | 160 | 0 |
|
Chip 2
|
A
|
2 | 0 | 99.87 | 99.31 | 0.46 | 26.3 | 80.7 | 2 | 0/0 | 0 | 1967 | 162 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.86 | 99.27 | 0.68 | 49.2 | 142.6 | 0 | 0/0 | 0 | 2130 | 164 | 0 |
|
Chip 4
|
A
|
26 | 0 | 99.88 | 99.34 | 0.71 | 46.4 | 136.5 | 26 | 0/0 | 0 | 2126 | 154 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.31 | 0.76 | 58.6 | 166.7 | 0 | 0/0 | 0 | 2207 | 157 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.89 | 99.38 | 0.46 | 60.1 | 171.7 | 0 | 0/0 | 0 | 2202 | 156 | 0 |
|
Chip 7
|
A
|
2 | 0 | 99.89 | 99.35 | 0.69 | 66.5 | 187.4 | 2 | 0/0 | 0 | 2256 | 157 | 0 |
|
Chip 8
|
A
|
2 | 0 | 99.89 | 99.39 | 0.63 | 70.7 | 201.6 | 2 | 0/0 | 0 | 2247 | 166 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.88 | 99.39 | 0.71 | 62.8 | 179.7 | 0 | 0/0 | 0 | 2176 | 169 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.38 | 0.55 | 60.5 | 173.0 | 0 | 0/0 | 0 | 2197 | 160 | 0 |
|
Chip 11
|
A
|
10 | 0 | 99.87 | 99.31 | 0.55 | 49.7 | 146.2 | 10 | 0/0 | 0 | 2144 | 156 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.22 | 1.38 | 51.1 | 149.4 | 0 | 0/0 | 0 | 2149 | 168 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.86 | 99.34 | 0.42 | 27.9 | 85.7 | 0 | 0/0 | 0 | 2001 | 168 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.86 | 99.04 | 0.75 | 32.8 | 98.6 | 1 | 0/0 | 0 | 2053 | 175 | 0 |
|
Chip 15
|
A
|
5 | 0 | 99.86 | 99.28 | 1.27 | 30.9 | 92.2 | 0 | 0/0 | 0 | 1961 | 163 | 2 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-08 | |
| TestTime | Test Time | 16:09 | |
| TestDuration | Duration | 1:23:4 | |
| pXar | pXar version | v2.7.5+30~g833b08f | |
| DTB_FW | DTB FW | 4.6 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
