Test Date: 2016-02-08 11:28
Analysis date: 2016-05-26 09:02
Analysis date: 2016-05-26 09:02
M2145 XRayHRQualification
Summary
| Module | Module | M2145 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 67 | |
| BumpBondingDefects | Bump Bonding Defects | 66 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.88/99.33 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 0 | 99.84 | 99.06 | 0.81 | 31.1 | 93.4 | 3 | 0/0 | 0 | 2006 | 175 | 0 |
|
Chip 1
|
A
|
1 | 0 | 99.86 | 99.29 | 0.72 | 29.3 | 89.6 | 1 | 0/0 | 0 | 1978 | 165 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.88 | 99.36 | 0.52 | 26.5 | 82.1 | 1 | 0/0 | 0 | 1944 | 159 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.39 | 0.54 | 48.9 | 142.7 | 0 | 0/0 | 0 | 2130 | 167 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.88 | 99.34 | 0.69 | 52.4 | 152.9 | 1 | 0/0 | 0 | 2138 | 162 | 0 |
|
Chip 5
|
A
|
1 | 0 | 99.88 | 99.41 | 0.65 | 65.6 | 188.0 | 1 | 0/0 | 0 | 2218 | 165 | 0 |
|
Chip 6
|
A
|
2 | 0 | 99.88 | 99.34 | 0.9 | 56.8 | 164.7 | 2 | 0/0 | 0 | 2159 | 164 | 0 |
|
Chip 7
|
A
|
6 | 0 | 99.89 | 99.40 | 0.66 | 65.8 | 187.9 | 6 | 0/0 | 0 | 2211 | 161 | 0 |
|
Chip 8
|
A
|
7 | 0 | 99.88 | 99.37 | 0.49 | 64.5 | 185.9 | 7 | 0/0 | 0 | 2214 | 165 | 0 |
|
Chip 9
|
A
|
12 | 0 | 99.88 | 99.37 | 0.69 | 52.4 | 154.2 | 12 | 0/0 | 0 | 2120 | 161 | 0 |
|
Chip 10
|
A
|
5 | 0 | 99.87 | 99.40 | 0.5 | 64.7 | 185.0 | 5 | 0/0 | 0 | 2231 | 172 | 0 |
|
Chip 11
|
A
|
1 | 0 | 99.88 | 99.33 | 0.49 | 49.8 | 145.0 | 1 | 0/0 | 0 | 2117 | 160 | 0 |
|
Chip 12
|
A
|
4 | 0 | 99.88 | 99.33 | 0.68 | 45.7 | 135.5 | 3 | 0/0 | 0 | 2107 | 161 | 1 |
|
Chip 13
|
A
|
1 | 0 | 99.88 | 99.31 | 0.4 | 25.3 | 78.9 | 1 | 0/0 | 0 | 1971 | 163 | 0 |
|
Chip 14
|
A
|
7 | 0 | 99.89 | 99.37 | 0.43 | 27.9 | 86.2 | 7 | 0/0 | 0 | 1983 | 167 | 0 |
|
Chip 15
|
A
|
15 | 0 | 99.87 | 99.29 | 0.58 | 30.0 | 90.4 | 15 | 0/0 | 0 | 1988 | 177 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-02-08 | |
| TestTime | Test Time | 11:28 | |
| TestDuration | Duration | 1:35:46 | |
| pXar | pXar version | prod-12 | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
