Test Date: 2016-01-12 12:57
Analysis date: 2016-05-26 07:50
Chip 3
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 150/50 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 150/50 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 150/50 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 150/50 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 150/50 0/0
Efficiency Efficiency 50/120 99.87/99.29
EfficiencyFit Efficiency Fit chi2/ndf: 0.54, # points: 112
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 150/50 A/A
HitMapGrade Hit Map Grade 150/50 A/(A)
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 150/50 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 150/50 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C3
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.54
NumberFitPoints # fit points 112
p0 p0 99.91
p1 p1 3.61e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.87
InterpolatedEfficiency120 Interpol. Efficiency 120 99.29
Efficiency Map 50: C3
Efficiency Map 75: C3
Efficiency Map 100: C3
Efficiency Map 125: C3
Efficiency Map 150: C3
Efficiency Map 200: C3
Efficiency Map 250: C3
Efficiency Distr. 50: C3
Plot
N N 4160
mu μ 99.86
sigma σ 0.54
Efficiency Distr. 75: C3
Plot
N N 4160
mu μ 99.75
sigma σ 0.71
Efficiency Distr. 100: C3
Plot
N N 4160
mu μ 99.44
sigma σ 1.16
Efficiency Distr. 125: C3
Plot
N N 4160
mu μ 99.11
sigma σ 1.57
Efficiency Distr. 150: C3
Plot
N N 4160
mu μ 98.57
sigma σ 2.11
Efficiency Distr. 200: C3
Plot
N N 4160
mu μ 96.56
sigma σ 4.11
Efficiency Distr. 250: C3
Plot
N N 4160
mu μ 93.69
sigma σ 6.58
Background Map 50: C3
Plot
RealHitrate Real Hitrate 48.62 MHz/cm2
Background Map 75: C3
Plot
RealHitrate Real Hitrate 71.42 MHz/cm2
Background Map 100: C3
Plot
RealHitrate Real Hitrate 98.12 MHz/cm2
Background Map 125: C3
Plot
RealHitrate Real Hitrate 118.80 MHz/cm2
Background Map 150: C3
Plot
RealHitrate Real Hitrate 140.80 MHz/cm2
Background Map 200: C3
Plot
RealHitrate Real Hitrate 190.52 MHz/cm2
Background Map 250: C3
Plot
RealHitrate Real Hitrate 233.21 MHz/cm2
Retrim Hot Pix 0: C3
Retrim Hot Pix 150: C3
Masked Hot Pixels 150: C3
Masked Hot Pixels 50: C3
Hit Map 150: C3
Plot
RealHitrate Real Hitrate 137.09 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C3
Hit Map 50: C3
Plot
RealHitrate Real Hitrate 46.68 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C3
Col. Read. Unif. 150: C3
Plot
N N 19320130
mu μ 426285
sigma σ 122787.78
Col. Read. Unif. 50: C3
Plot
N N 6559483
mu μ 145172
sigma σ 44896.84
Read. Unif. over Time 150: C3
Plot
N N 22166803
mu μ 22482
sigma_th σ_th 149.94
Time unif. distribution 150: C3
Plot
chi2/ndf chi2/ndf 25.80
sigma σ 187.06
sigma_th σ_th 149.96
expectation Red curve (expected) Poisson
Read. Unif. over Time 50: C3
Plot
N N 7548964
mu μ 7656
sigma_th σ_th 87.50
Time unif. distribution 50: C3
Plot
chi2/ndf chi2/ndf 1.62
sigma σ 90.89
sigma_th σ_th 87.50
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C3
Col. Uniformity per Event: C3 150
Plot
mu μ 24.95
sigma fit error of μ 2.22
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C3 50
Plot
mu μ 24.46
sigma fit error of μ 2.19
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C3 100
Plot
N N 4160
mu μ 146.53
sigma RMS 13.91
threshold thr 2100.03
fit fit Gaussian
fit_peak μ fit 146.35
fit_sigma σ fit 14.02
MeasuredHitrate Measured hitrate: 97.5
Alive Map: C3
DC Efficiency Distribution: C3
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.29
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C3
