Test Date: 2015-07-24 10:42
Analysis date: 2016-05-25 23:14
M2048 ModuleFulltestPxar_m20_2
Chips

Overview

_
Summary 1
Module Module M2048
Grade Grade A
ElectricalGrade Electrical Grade A
IVGrade IV Grade A
ManualGrade Manual Grade None
PixelDefects Pixel Defects - A/B/C 22 - 16/0/0
DeadPixels Dead Pixels 2
AddressProblems Address Problems 0
ThresholdDefects Threshold Defects 8
MaskDefects Mask Defects 0
DeadBumps Dead Bumps 12
NoisyPixels Noise Defects 0
TrimProblems Trim Problems 0
PHGainDefects PH Gain Defects 0
PHPar1Defects PH Parameter1 Defects 0
Summary 2
TestCenter Test Center ETH
TestDate Test Date 2015-07-24
TestTime Test Time 10:42
TestDuration Duration 1:22:01
TempC Temparature -20 °C
TBM1 TBM1 ok, 0x34 0x64
TBM2 TBM2 ok, 0x00 0x64
PxarVersion pXar v2.2.5+46 gdbe75a1
DTB_FW DTB FW 4.0
ModuleIa Module Ia 379.4 mA
Summary 3
Noise Noise 114.45 e
NoiseROCs Noise grades 16/0/0
VcalThrWidth Vcal Thr. Width 51.78 e
VcalThrWidthROCs Vcal Thr. W. grades 16/0/0
RelGainWidth Rel. Gain Width 0.03 %
RelGainWidthROCs Rel. Gain W. grades 16/0/0
PedestalSpread Pedestal Spread 1012.41 e
PedestalSpreadROCs Ped. Spread grades 16/0/0
Parameter1 Parameter1 0.71
Parameter1ROCs Par1 grades 16/0/0
CurrentAtVoltage150V I_rec(150 V) @ 17°C 16.09 μA
CurrentAtVoltage150V_ORIG I_orig(150V) @ -20.0 °C 0.36 μA
CurrentVariation I(150 V) / I(100 V) 1.95
IVCurve
CurrentAtVoltage150V I_orig(150V) @ -20.0 °C 0.36 μA
Variation I(150 V) / I(100 V) 1.95
recalculatedCurrentAtVoltage150V I_rec(150 V) @ 17°C 16.09 μA
recalculatedCurrentVariation I_rec(150 V) / I_rec(100 V) 1.95
CurrentRatio100V I(+17C)/I(-20C) 100V 5.64
CurrentRatio150V I(+17C)/I(-20C) 150V 4.19
Noise
Vcal Threshold Width
RelativeGainWidth
PedestalSpread
Parameter1
CalDel
mu μ 134.06
caldelspread CalDel spread 23
PHScale
mu μ 88.88
phscalespread PHScale spread 24
PHOffset
mu μ 150.94
phoffsetspread PHOffset spread 40
VthrComp
mu μ 86.62
vthrcompspread VthrComp spread 34
Vtrim
mu μ 112.06
vtrimspread Vtrim spread 102
Vana
mu μ 82.88
vanaspread Vana spread 31
Digital Current
Duration Duration 1:22:01
MinCurrent min. Current 0.439 A
MaxCurrent max. Current 0.474 A
Analog Current
Duration Duration 1:22:01
MinCurrent min. Current 0.35 A
MaxCurrent max. Current 0.383 A
ModuleIa Module Ia 379.4 mA
Temperature
Temperature Temp. while test -20.00 +/- 0.02 °C
Duration Duration of test 0:09:31
Summary ROCs
ROC Grade Total Dead Mask Bumps Trim(Bits) Address Noise Thresh Gain Ped Par1 Mean noise Thr [e-] Thr width Rel gain width Ped spread
Chip 0
A
6
0
0
6
0
0
0
0
0
0
0
110.36
1753
52
0.035
931
Chip 1
A
1
1
0
0
0
0
0
0
0
0
0
127.13
1755
55
0.033
1069
Chip 2
A
1
0
0
1
0
0
0
0
0
0
0
115.05
1750
50
0.041
866
Chip 3
A
9
1
0
0
0
0
0
8
0
0
0
110.62
1752
62
0.036
976
Chip 4
A
0
0
0
0
0
0
0
0
0
0
0
128.56
1752
54
0.031
1313
Chip 5
A
2
0
0
2
0
0
0
0
0
0
0
122.05
1753
54
0.032
1077
Chip 6
A
1
0
0
1
0
0
0
0
0
0
0
116.03
1752
51
0.033
1034
Chip 7
A
0
0
0
0
0
0
0
0
0
0
0
101.27
1754
48
0.036
928
Chip 8
A
0
0
0
0
0
0
0
0
0
0
0
122.57
1752
52
0.031
1016
Chip 9
A
0
0
0
0
0
0
0
0
0
0
0
111.05
1752
50
0.035
923
Chip 10
A
0
0
0
0
0
0
0
0
0
0
0
120.50
1753
52
0.030
1118
Chip 11
A
0
0
0
0
0
0
0
0
0
0
0
104.28
1752
50
0.031
1113
Chip 12
A
1
0
0
1
0
0
0
0
0
0
0
123.44
1754
49
0.039
946
Chip 13
A
0
0
0
0
0
0
0
0
0
0
0
112.40
1753
53
0.029
1024
Chip 14
A
1
0
0
1
0
0
0
0
0
0
0
98.70
1752
48
0.029
1024
Chip 15
A
0
0
0
0
0
0
0
0
0
0
0
107.18
1753
52
0.029
840
Readback par0vd
Readback par1vd
Readback par0va
Readback par1va
Readback par0rbia
Readback par1rbia
Readback par0tbia
Readback par1tbia
Readback par2tbia
Readback par0ia
Readback par1ia
Readback par2ia
GradingParameters
ModifiedGrading Modified Grading True
GradingParameters_leakageCurrentRatioB leakageCurrentRatioB 20 => -111
TBM
nTBMs n 1
TBMType Type tbm09c
Core0a_basea Core 0a base a 0x64
Core0a_basee Core 0a base e 0x34
Core0b_basea Core 0b base a 0x64
Core0b_basee Core 0b base e 0x00
RocDelay_Ch0 Roc Delay Ch0 4
RocDelay_Ch1 Roc Delay Ch1 4
RocDelay_Ch2 Roc Delay Ch2 4
RocDelay_Ch3 Roc Delay Ch3 4
Phase400 Phase 400 5
Phase160 Phase 160 1
Logfile

Overview

Errors
nCriticals # Criticals 0
nErrors # Errors 37
nWarnings # Warnings 22
channel_0_count Channel 0 0
channel_1_count Channel 1 0
channel_2_count Channel 2 0
channel_3_count Channel 3 59
message_eventid_count Event ID mismatch 13
message_readback_count Readback start marker 22
message_tokenchain_count Token Chain Length 24
