Module | Module | M2041 | |
Grade | Grade | A | |
ElectricalGrade | Electrical Grade | A | |
IVGrade | IV Grade | A | |
ManualGrade | Manual Grade | None | |
PixelDefects | Pixel Defects - A/B/C | 27 - 16/0/0 | |
DeadPixels | Dead Pixels | 0 | |
AddressProblems | Address Problems | 0 | |
ThresholdDefects | Threshold Defects | 7 | |
MaskDefects | Mask Defects | 0 | |
DeadBumps | Dead Bumps | 17 | |
NoisyPixels | Noise Defects | 3 | |
TrimProblems | Trim Problems | 1 | |
PHGainDefects | PH Gain Defects | 1 | |
PHPar1Defects | PH Parameter1 Defects | 0 |
TestCenter | Test Center | ETH | |
TestDate | Test Date | 2015-08-19 | |
TestTime | Test Time | 10:30 | |
TestDuration | Duration | 1:15:29 | |
TempC | Temparature | -20 | °C |
TBM1 | TBM1 | ok, 0x6c 0x40 | |
TBM2 | TBM2 | ok, 0x00 0x49 | |
PxarVersion | pXar | v2.2.5+88 g694c14c | |
DTB_FW | DTB FW | 4.0 | |
ModuleIa | Module Ia | 387.5 | mA |
Noise | Noise | 117.18 | e |
NoiseROCs | Noise grades | 16/0/0 | |
VcalThrWidth | Vcal Thr. Width | 52.41 | e |
VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
RelGainWidth | Rel. Gain Width | 0.04 | % |
RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
PedestalSpread | Pedestal Spread | 1028.12 | e |
PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
Parameter1 | Parameter1 | 0.70 | |
Parameter1ROCs | Par1 grades | 16/0/0 | |
CurrentAtVoltage150V | I_rec(150 V) @ 17°C | 0.86 | μA |
CurrentAtVoltage150V_ORIG | I_orig(150V) @ -20.0 °C | 0.02 | μA |
CurrentVariation | I(150 V) / I(100 V) | 1.37 |
CurrentAtVoltage150V | I_orig(150V) @ -20.0 °C | 0.02 | μA |
Variation | I(150 V) / I(100 V) | 1.37 | |
recalculatedCurrentAtVoltage150V | I_rec(150 V) @ 17°C | 0.86 | μA |
recalculatedCurrentVariation | I_rec(150 V) / I_rec(100 V) | 1.37 | |
CurrentRatio100V | I(+17C)/I(-20C) 100V | 26.01 | |
CurrentRatio150V | I(+17C)/I(-20C) 150V | 21.74 |
Duration | Duration | 1:15:29 | |
MinCurrent | min. Current | 0.442 | A |
MaxCurrent | max. Current | 0.478 | A |
Duration | Duration | 1:15:29 | |
MinCurrent | min. Current | 0.368 | A |
MaxCurrent | max. Current | 0.391 | A |
ModuleIa | Module Ia | 387.5 | mA |
Temperature | Temp. while test | -20.00 +/- 0.01 | °C |
Duration | Duration of test | 1:15:36 |
ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chip 0 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
105.04
|
1751 |
50
|
0.037
|
868
|
Chip 1 |
A
|
2
|
0
|
0
|
1
|
1
|
0
|
1
|
0
|
1
|
0
|
0
|
125.05
|
1752 |
53
|
0.038
|
1031
|
Chip 2 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
129.78
|
1752 |
52
|
0.041
|
1091
|
Chip 3 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
121.76
|
1752 |
53
|
0.045
|
939
|
Chip 4 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
136.17
|
1751 |
57
|
0.033
|
1350
|
Chip 5 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
0
|
137.57
|
1755 |
56
|
0.029
|
951
|
Chip 6 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
116.42
|
1753 |
55
|
0.033
|
1246
|
Chip 7 |
A
|
8
|
0
|
0
|
7
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
101.77
|
1751 |
54
|
0.034
|
876
|
Chip 8 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
130.18
|
1750 |
55
|
0.043
|
1156
|
Chip 9 |
A
|
2
|
0
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
105.40
|
1751 |
50
|
0.042
|
1036
|
Chip 10 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
121.70
|
1752 |
52
|
0.044
|
1208
|
Chip 11 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
108.68
|
1754 |
49
|
0.031
|
1014
|
Chip 12 |
A
|
5
|
0
|
0
|
5
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
99.91
|
1750 |
52
|
0.029
|
941
|
Chip 13 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
127.07
|
1752 |
52
|
0.040
|
872
|
Chip 14 |
A
|
2
|
0
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
105.56
|
1753 |
52
|
0.029
|
945
|
Chip 15 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
102.88
|
1751 |
50
|
0.036
|
927
|
ModifiedGrading | Modified Grading | True | |
GradingParameters_leakageCurrentRatioB | leakageCurrentRatioB | 20 => -111 |
nTBMs | n | 1 | |
TBMType | Type | tbm09c | |
Core0a_basea | Core 0a base a | 0x40 | |
Core0a_basee | Core 0a base e | 0x6c | |
Core0b_basea | Core 0b base a | 0x49 | |
Core0b_basee | Core 0b base e | 0x00 | |
RocDelay_Ch0 | Roc Delay Ch0 | 0 | |
RocDelay_Ch1 | Roc Delay Ch1 | 0 | |
RocDelay_Ch2 | Roc Delay Ch2 | 1 | |
RocDelay_Ch3 | Roc Delay Ch3 | 1 | |
Phase400 | Phase 400 | 3 | |
Phase160 | Phase 160 | 3 |
nCriticals | # Criticals | 0 | |
nErrors | # Errors | 41 | |
nWarnings | # Warnings | 34 | |
channel_0_count | Channel 0 | 0 | |
channel_1_count | Channel 1 | 0 | |
channel_2_count | Channel 2 | 0 | |
channel_3_count | Channel 3 | 75 | |
message_eventid_count | Event ID mismatch | 16 | |
message_readback_count | Readback start marker | 34 | |
message_tokenchain_count | Token Chain Length | 25 |
