Test Date: 2015-07-13 11:39
Analysis date: 2016-05-25 22:29
Chip 5
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 150/50 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 150/50 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 150/50 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 150/50 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 150/50 4/4
Efficiency Efficiency 50/120 99.86/99.1
EfficiencyFit Efficiency Fit chi2/ndf: 0.72, # points: 45
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 150/50 A/A
HitMapGrade Hit Map Grade 150/50 A/(A)
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 150/50 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 150/50 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade B
Efficiency Interpolation: C5
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.72
NumberFitPoints # fit points 45
p0 p0 99.92
p1 p1 4.77e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.86
InterpolatedEfficiency120 Interpol. Efficiency 120 99.10
Efficiency Map 50: C5
Efficiency Map 100: C5
Efficiency Map 150: C5
Efficiency Map 200: C5
Efficiency Map 250: C5
Efficiency Distr. 50: C5
Plot
N N 4160
mu μ 99.67
sigma σ 2.31
Efficiency Distr. 100: C5
Plot
N N 4160
mu μ 98.43
sigma σ 3.02
Efficiency Distr. 150: C5
Plot
N N 4160
mu μ 95.37
sigma σ 5.04
Efficiency Distr. 200: C5
Plot
N N 4160
mu μ 89.55
sigma σ 8.36
Efficiency Distr. 250: C5
Plot
N N 4160
mu μ 88.69
sigma σ 8.81
Background Map 50: C5
Plot
RealHitrate Real Hitrate 67.49 MHz/cm2
Background Map 100: C5
Plot
RealHitrate Real Hitrate 133.61 MHz/cm2
Background Map 150: C5
Plot
RealHitrate Real Hitrate 191.83 MHz/cm2
Background Map 200: C5
Plot
RealHitrate Real Hitrate 256.27 MHz/cm2
Background Map 250: C5
Plot
RealHitrate Real Hitrate 263.84 MHz/cm2
Retrim Hot Pix 150: C5
Masked Hot Pixels 150: C5
Masked Hot Pixels 50: C5
Hit Map 150: C5
Plot
RealHitrate Real Hitrate 190.26 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 6
BB Defects 150: C5
Hit Map 50: C5
Plot
RealHitrate Real Hitrate 66.81 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 6
BB Defects 50: C5
Col. Read. Unif. 150: C5
Plot
N N 26933108
mu μ 591568
sigma σ 150605.45
Col. Read. Unif. 50: C5
Plot
N N 9433373
mu μ 207773
sigma σ 55636.89
Read. Unif. over Time 150: C5
Plot
N N 30761511
mu μ 31198
sigma_th σ_th 176.63
Time unif. distribution 150: C5
Plot
chi2/ndf chi2/ndf 7.02
sigma σ 198.85
sigma_th σ_th 176.66
expectation Red curve (expected) Poisson
Read. Unif. over Time 50: C5
Plot
N N 10804202
mu μ 10958
sigma_th σ_th 104.68
Time unif. distribution 50: C5
Plot
chi2/ndf chi2/ndf 0.87
sigma σ 109.19
sigma_th σ_th 104.68
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C5
Col. Uniformity per Event: C5 150
Plot
mu μ 26.06
sigma fit error of μ 2.23
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C5 50
Plot
mu μ 26.25
sigma fit error of μ 2.24
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C5 100
Plot
N N 4155
mu μ 371.25
sigma RMS 71.81
threshold thr 3211.69
fit fit Gaussian
fit_peak μ fit 366.00
fit_sigma σ fit 58.53
MeasuredHitrate Measured hitrate: 135.0
over >= 5.00
Alive Map: C5
DC Efficiency Distribution: C5
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.08
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C5
