Test Date: 2015-07-13 11:39
Analysis date: 2016-05-25 22:29
Chip 2
Grading
ROCGrade Final ROC Grade C
NumberOfHotPixels # Hot Pixels 150/50 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 150/50 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 150/50 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 150/50 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 150/50 8/8
Efficiency Efficiency 50/120 99.84/99.04
EfficiencyFit Efficiency Fit chi2/ndf: 0.76, # points: 76
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 150/50 A/A
HitMapGrade Hit Map Grade 150/50 A/(A)
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 150/50 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 150/50 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade B
Efficiency Interpolation: C2
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.76
NumberFitPoints # fit points 76
p0 p0 99.90
p1 p1 5.00e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.84
InterpolatedEfficiency120 Interpol. Efficiency 120 99.04
Efficiency Map 50: C2
Efficiency Map 100: C2
Efficiency Map 150: C2
Efficiency Map 200: C2
Efficiency Map 250: C2
Efficiency Distr. 50: C2
Plot
N N 4160
mu μ 99.94
sigma σ 0.36
Efficiency Distr. 100: C2
Plot
N N 4160
mu μ 99.73
sigma σ 0.87
Efficiency Distr. 150: C2
Plot
N N 4160
mu μ 99.27
sigma σ 1.84
Efficiency Distr. 200: C2
Plot
N N 4160
mu μ 98.39
sigma σ 3.61
Efficiency Distr. 250: C2
Plot
N N 4160
mu μ 98.19
sigma σ 3.77
Background Map 50: C2
Plot
RealHitrate Real Hitrate 26.47 MHz/cm2
Background Map 100: C2
Plot
RealHitrate Real Hitrate 54.47 MHz/cm2
Background Map 150: C2
Plot
RealHitrate Real Hitrate 79.92 MHz/cm2
Background Map 200: C2
Plot
RealHitrate Real Hitrate 109.40 MHz/cm2
Background Map 250: C2
Plot
RealHitrate Real Hitrate 114.28 MHz/cm2
Retrim Hot Pix 150: C2
Masked Hot Pixels 150: C2
Masked Hot Pixels 50: C2
Hit Map 150: C2
Plot
RealHitrate Real Hitrate 79.50 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 8
BB Defects 150: C2
Hit Map 50: C2
Plot
RealHitrate Real Hitrate 26.24 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 8
BB Defects 50: C2
Col. Read. Unif. 150: C2
Plot
N N 10813156
mu μ 247190
sigma σ 152598.34
Col. Read. Unif. 50: C2
Plot
N N 3540365
mu μ 81608
sigma σ 56082.32
Read. Unif. over Time 150: C2
Plot
N N 12853894
mu μ 13036
sigma_th σ_th 114.18
Time unif. distribution 150: C2
Plot
chi2/ndf chi2/ndf 3.01
sigma σ 120.84
sigma_th σ_th 114.19
expectation Red curve (expected) Poisson
Read. Unif. over Time 50: C2
Plot
N N 4243602
mu μ 4304
sigma_th σ_th 65.60
Time unif. distribution 50: C2
Plot
chi2/ndf chi2/ndf 1.57
sigma σ 68.35
sigma_th σ_th 65.61
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C2
Col. Uniformity per Event: C2 150
Plot
mu μ 29.95
sigma fit error of μ 2.45
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C2 50
Plot
mu μ 30.52
sigma fit error of μ 2.46
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C2 100
Plot
N N 4147
mu μ 363.42
sigma RMS 85.47
threshold thr 3281.77
fit fit Gaussian
fit_peak μ fit 356.57
fit_sigma σ fit 62.07
MeasuredHitrate Measured hitrate: 55.4
under <= 5.00
over >= 8.00
Alive Map: C2
DC Efficiency Distribution: C2
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.86
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 98.77
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C2
