Test Date: 2015-07-13 11:39
Analysis date: 2016-05-25 22:29
Chip 15
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 150/50 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 150/50 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 150/50 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 150/50 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 150/50 22/21
Efficiency Efficiency 50/120 99.85/99.06
EfficiencyFit Efficiency Fit chi2/ndf: 0.48, # points: 96
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 150/50 A/A
HitMapGrade Hit Map Grade 150/50 A/(A)
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 150/50 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 150/50 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C15
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.48
NumberFitPoints # fit points 96
p0 p0 99.91
p1 p1 4.88e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.85
InterpolatedEfficiency120 Interpol. Efficiency 120 99.06
Efficiency Map 50: C15
Efficiency Map 100: C15
Efficiency Map 150: C15
Efficiency Map 200: C15
Efficiency Map 250: C15
Efficiency Distr. 50: C15
Plot
N N 4160
mu μ 99.94
sigma σ 0.36
Efficiency Distr. 100: C15
Plot
N N 4160
mu μ 99.80
sigma σ 0.63
Efficiency Distr. 150: C15
Plot
N N 4160
mu μ 99.51
sigma σ 1.05
Efficiency Distr. 200: C15
Plot
N N 4160
mu μ 99.01
sigma σ 1.56
Efficiency Distr. 250: C15
Plot
N N 4160
mu μ 98.88
sigma σ 1.66
Background Map 50: C15
Plot
RealHitrate Real Hitrate 28.15 MHz/cm2
Background Map 100: C15
Plot
RealHitrate Real Hitrate 57.21 MHz/cm2
Background Map 150: C15
Plot
RealHitrate Real Hitrate 83.46 MHz/cm2
Background Map 200: C15
Plot
RealHitrate Real Hitrate 114.14 MHz/cm2
Background Map 250: C15
Plot
RealHitrate Real Hitrate 117.86 MHz/cm2
Retrim Hot Pix 150: C15
Masked Hot Pixels 150: C15
Masked Hot Pixels 50: C15
Hit Map 150: C15
Plot
RealHitrate Real Hitrate 84.43 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 22
BB Defects 150: C15
Hit Map 50: C15
Plot
RealHitrate Real Hitrate 28.20 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 21
BB Defects 50: C15
Col. Read. Unif. 150: C15
Plot
N N 11965421
mu μ 262527
sigma σ 68152.14
Col. Read. Unif. 50: C15
Plot
N N 3982152
mu μ 87692
sigma σ 24436.57
Read. Unif. over Time 150: C15
Plot
N N 13651380
mu μ 13845
sigma_th σ_th 117.67
Time unif. distribution 150: C15
Plot
chi2/ndf chi2/ndf 2.23
sigma σ 125.81
sigma_th σ_th 117.68
expectation Red curve (expected) Poisson
Read. Unif. over Time 50: C15
Plot
N N 4559990
mu μ 4625
sigma_th σ_th 68.01
Time unif. distribution 50: C15
Plot
chi2/ndf chi2/ndf 0.88
sigma σ 69.13
sigma_th σ_th 68.01
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C15
Col. Uniformity per Event: C15 150
Plot
mu μ 26.06
sigma fit error of μ 2.20
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C15 50
Plot
mu μ 26.01
sigma fit error of μ 2.21
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C15 100
Plot
N N 4160
mu μ 168.87
sigma RMS 15.47
threshold thr 2120.63
fit fit Gaussian
fit_peak μ fit 168.75
fit_sigma σ fit 15.28
MeasuredHitrate Measured hitrate: 58.7
Alive Map: C15
DC Efficiency Distribution: C15
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 99.06
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C15
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
