Test Date: 2015-07-13 11:39
Analysis date: 2016-05-25 22:29
Chip 13
Grading
ROCGrade Final ROC Grade A
NumberOfHotPixels # Hot Pixels 150/50 0/0
NumberOfNonUniformColumns # Non-Uniform Columns 150/50 0
NumberOfNonUniformEvents # Non-Uniform ROC Events 150/50 0/0
NumberOfNonUniformColumnEvents # Non-Uniform Col. Events 150/50 0/0
BadDoubleColumns # Bad Double Columns 0
BumpBondingDefects # Bump Bonding Defects 150/50 0/0
Efficiency Efficiency 50/120 99.82/99.08
EfficiencyFit Efficiency Fit chi2/ndf: 0.73, # points: 72
EfficiencyGrade Efficiency Grade 50/120 (A)/A
BadDoubleColumnsGrade Bad DC Grade A
HotPixelsGrade Hot Pixels Grade 150/50 A/A
HitMapGrade Hit Map Grade 150/50 A/(A)
ReadoutUniformityOverTimeGrade ROC Read. Unif. Grade 150/50 A/A
ColumnReadoutUniformityOverTimeGrade Column Read. Unif. Grade 150/50 A/A
ColumnUniformityGrade Column Uniformity Grade A
NoiseGrade Noise Grade A
Efficiency Interpolation: C13
Plot
fitfunction Fit [0]-[1]*x^3
BadDoubleColumns # Bad DCs (excluded from fit) 0
Chi2NDF chi2/ndf 0.73
NumberFitPoints # fit points 72
p0 p0 99.88
p1 p1 4.59e-07
InterpolatedEfficiency50 Interpol. Efficiency 50 99.82
InterpolatedEfficiency120 Interpol. Efficiency 120 99.08
Efficiency Map 50: C13
Efficiency Map 100: C13
Efficiency Map 150: C13
Efficiency Map 200: C13
Efficiency Map 250: C13
Efficiency Distr. 50: C13
Plot
N N 4160
mu μ 99.92
sigma σ 0.40
Efficiency Distr. 100: C13
Plot
N N 4160
mu μ 99.63
sigma σ 1.12
Efficiency Distr. 150: C13
Plot
N N 4160
mu μ 98.98
sigma σ 2.44
Efficiency Distr. 200: C13
Plot
N N 4160
mu μ 97.61
sigma σ 5.07
Efficiency Distr. 250: C13
Plot
N N 4160
mu μ 97.49
sigma σ 5.44
Background Map 50: C13
Plot
RealHitrate Real Hitrate 29.55 MHz/cm2
Background Map 100: C13
Plot
RealHitrate Real Hitrate 60.29 MHz/cm2
Background Map 150: C13
Plot
RealHitrate Real Hitrate 88.18 MHz/cm2
Background Map 200: C13
Plot
RealHitrate Real Hitrate 120.69 MHz/cm2
Background Map 250: C13
Plot
RealHitrate Real Hitrate 125.65 MHz/cm2
Retrim Hot Pix 150: C13
Masked Hot Pixels 150: C13
Masked Hot Pixels 50: C13
Hit Map 150: C13
Plot
RealHitrate Real Hitrate 88.65 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 150: C13
Hit Map 50: C13
Plot
RealHitrate Real Hitrate 29.32 MHz/cm2
NumberOfDefectivePixels # Defective Pixels 0
BB Defects 50: C13
Col. Read. Unif. 150: C13
Plot
N N 12004384
mu μ 275639
sigma σ 185933.21
Col. Read. Unif. 50: C13
Plot
N N 3938220
mu μ 91194
sigma σ 68126.69
Read. Unif. over Time 150: C13
Plot
N N 14333239
mu μ 14537
sigma_th σ_th 120.57
Time unif. distribution 150: C13
Plot
chi2/ndf chi2/ndf 1.32
sigma σ 127.71
sigma_th σ_th 120.59
expectation Red curve (expected) Poisson
Read. Unif. over Time 50: C13
Plot
N N 4742097
mu μ 4809
sigma_th σ_th 69.35
Time unif. distribution 50: C13
Plot
chi2/ndf chi2/ndf 2.41
sigma σ 74.09
sigma_th σ_th 69.35
expectation Red curve (expected) Poisson
Col. Uniformity Ratio: C13
Col. Uniformity per Event: C13 150
Plot
mu μ 21.80
sigma fit error of μ 2.46
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
Col. Uniformity per Event: C13 50
Plot
mu μ 21.27
sigma fit error of μ 2.49
NumberOfNonUniformColumnEvents Non uniform 10.000 event bins 0
S-Curve widths: Noise (e^{-}) C13 100
Plot
N N 4160
mu μ 231.32
sigma RMS 43.72
threshold thr 2539.96
fit fit Gaussian
fit_peak μ fit 230.32
fit_sigma σ fit 39.73
MeasuredHitrate Measured hitrate: 61.1
Alive Map: C13
DC Efficiency Distribution: C13
Plot
MeanEfficiency_50 Mean Efficiency 50 MHz/cm2 99.87
MeanEfficiency_120 Mean Efficiency 120 MHz/cm2 98.87
NBadDoubleColumns Bad Double Columns 0
CalDel scan: C13
