Test Date: 2015-09-11 16:58
Analysis date: 2016-05-25 21:50
Analysis date: 2016-05-25 21:50
M2034 XRayHRQualification
Summary
| Module | Module | M2034 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 35 | |
| BumpBondingDefects | Bump Bonding Defects | 31 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.87/99.29 | % |
| Noise | Mean Noise | 166 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "150" | BB def | Rate "50" | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
6 | 0 | 99.87 | 99.25 | 0.68 | 76.9 | 6 | 26.2 | 0/0 | 0 | 1911 | 161 | 0 |
|
Chip 1
|
A
|
2 | 0 | 99.89 | 99.33 | 0.44 | 82.2 | 2 | 27.8 | 0/0 | 0 | 1934 | 160 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.26 | 0.52 | 77.7 | 0 | 25.9 | 0/0 | 0 | 1888 | 166 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.90 | 99.35 | 0.67 | 138.8 | 1 | 48.0 | 0/0 | 0 | 2055 | 175 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.89 | 99.38 | 0.49 | 143.5 | 0 | 49.8 | 0/0 | 0 | 2066 | 172 | 1 |
|
Chip 5
|
A
|
0 | 0 | 99.89 | 99.38 | 0.49 | 162.5 | 0 | 57.5 | 0/0 | 0 | 2132 | 166 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.36 | 0.49 | 169.8 | 0 | 58.6 | 0/0 | 0 | 2135 | 173 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.86 | 99.36 | 0.61 | 162.5 | 1 | 56.1 | 0/0 | 0 | 2106 | 171 | 0 |
|
Chip 8
|
A
|
3 | 0 | 99.85 | 99.32 | 1.45 | 145.5 | 2 | 49.7 | 0/0 | 0 | 2083 | 170 | 0 |
|
Chip 9
|
A
|
1 | 0 | 99.85 | 99.28 | 0.77 | 149.4 | 1 | 51.4 | 0/0 | 0 | 2092 | 176 | 0 |
|
Chip 10
|
A
|
1 | 0 | 99.88 | 99.24 | 1.58 | 140.8 | 1 | 49.3 | 0/0 | 0 | 2103 | 161 | 0 |
|
Chip 11
|
A
|
3 | 0 | 99.88 | 99.33 | 0.55 | 123.5 | 3 | 42.6 | 0/0 | 0 | 2026 | 168 | 0 |
|
Chip 12
|
A
|
3 | 0 | 99.86 | 99.29 | 1.14 | 119.7 | 2 | 40.9 | 0/0 | 0 | 1996 | 170 | 0 |
|
Chip 13
|
A
|
5 | 0 | 99.86 | 99.33 | 0.34 | 64.8 | 4 | 21.5 | 0/0 | 0 | 1898 | 155 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 98.98 | 0.36 | 67.1 | 0 | 22.3 | 0/0 | 0 | 1930 | 157 | 0 |
|
Chip 15
|
A
|
8 | 0 | 99.86 | 99.21 | 0.34 | 70.0 | 8 | 23.8 | 0/0 | 0 | 1920 | 159 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2015-09-11 | |
| TestTime | Test Time | 16:58 | |
| TestDuration | Duration | 1:26:36 | |
| pXar | pXar version | prod-10+24~g09f6d2c | |
| DTB_FW | DTB FW | 4.5 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 8 | |
| nWarnings | # Warnings | 2 | |
| channel_0_count | Channel 0 | 2 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_readback_count | Readback start marker | 2 |
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
