Test Date: 2015-07-07 08:06
Analysis date: 2016-05-25 21:25
X-ray Calibration - Spectrum
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
44.4205 |
|
| medianSlope |
median Slope |
44.789 |
|
| minSlope |
min Slope |
40.111 |
|
| maxSlope |
max Slope |
49.092 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
263.749625 |
|
| medianOffset |
median Offset |
238.6145 |
|
| minOffset |
min Offset |
113.623 |
|
| maxOffset |
max Offset |
460.848 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.8909375 |
|
| medianchi2 |
median chi2 |
1.206 |
|
| minchi2 |
min chi2 |
0.013 |
|
| maxchi2 |
max chi2 |
13.497 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
46.5 e- / Vcal
|
0.1 e- / Vcal
|
343.9 e-
|
14.2 e-
|
|
1
|
47.3 e- / Vcal
|
0.1 e- / Vcal
|
460.8 e-
|
15.1 e-
|
|
2
|
49.1 e- / Vcal
|
0.2 e- / Vcal
|
378.2 e-
|
17.8 e-
|
|
3
|
44.9 e- / Vcal
|
0.1 e- / Vcal
|
442.0 e-
|
14.4 e-
|
|
4
|
45.0 e- / Vcal
|
0.1 e- / Vcal
|
198.0 e-
|
6.4 e-
|
|
5
|
46.2 e- / Vcal
|
0.1 e- / Vcal
|
185.7 e-
|
13.9 e-
|
|
6
|
44.6 e- / Vcal
|
0.1 e- / Vcal
|
232.2 e-
|
15.1 e-
|
|
7
|
42.3 e- / Vcal
|
0.1 e- / Vcal
|
245.0 e-
|
16.8 e-
|
|
8
|
42.7 e- / Vcal
|
0.2 e- / Vcal
|
168.9 e-
|
20.1 e-
|
|
9
|
44.7 e- / Vcal
|
0.1 e- / Vcal
|
201.2 e-
|
6.3 e-
|
|
10
|
42.9 e- / Vcal
|
0.1 e- / Vcal
|
124.4 e-
|
16.2 e-
|
|
11
|
45.1 e- / Vcal
|
0.1 e- / Vcal
|
123.9 e-
|
17.1 e-
|
|
12
|
40.9 e- / Vcal
|
0.1 e- / Vcal
|
278.4 e-
|
12.4 e-
|
|
13
|
40.1 e- / Vcal
|
0.1 e- / Vcal
|
113.6 e-
|
19.1 e-
|
|
14
|
43.4 e- / Vcal
|
0.1 e- / Vcal
|
333.1 e-
|
15.4 e-
|
|
15
|
45.0 e- / Vcal
|
0.1 e- / Vcal
|
390.7 e-
|
15.8 e-
|
|
Average
|
44.4 e- / Vcal
|
|
263.7 e-
|
|
|
Median
|
85.0 e- / Vcal
|
|
413.9 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
MoReWeb-v1.0.0-5-g82d9ff6 on branch psi46master
