Module | Module | M2028 | |
Grade | Grade | A | |
ElectricalGrade | Electrical Grade | A | |
IVGrade | IV Grade | A | |
ManualGrade | Manual Grade | None | |
PixelDefects | Pixel Defects - A/B/C | 60 - 16/0/0 | |
DeadPixels | Dead Pixels | 3 | |
AddressProblems | Address Problems | 0 | |
ThresholdDefects | Threshold Defects | 22 | |
MaskDefects | Mask Defects | 0 | |
DeadBumps | Dead Bumps | 35 | |
NoisyPixels | Noise Defects | 0 | |
TrimProblems | Trim Problems | 0 | |
PHGainDefects | PH Gain Defects | 0 | |
PHPar1Defects | PH Parameter1 Defects | 0 |
TestCenter | Test Center | ETH | |
TestDate | Test Date | 2015-08-18 | |
TestTime | Test Time | 11:20 | |
TestDuration | Duration | 1:15:18 | |
TempC | Temparature | 17 | °C |
TBM1 | TBM1 | ok, 0x6c 0x40 | |
TBM2 | TBM2 | ok, 0x00 0x49 | |
PxarVersion | pXar | v2.2.5+88 g694c14c | |
DTB_FW | DTB FW | 4.0 | |
ModuleIa | Module Ia | 382.7 | mA |
Noise | Noise | 131.11 | e |
NoiseROCs | Noise grades | 16/0/0 | |
VcalThrWidth | Vcal Thr. Width | 54.06 | e |
VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
RelGainWidth | Rel. Gain Width | 0.03 | % |
RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
PedestalSpread | Pedestal Spread | 1188.22 | e |
PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
Parameter1 | Parameter1 | 0.67 | |
Parameter1ROCs | Par1 grades | 16/0/0 | |
CurrentAtVoltage150V | I(150 V) | 0.57 | μA |
CurrentVariation | I(150 V) / I(100 V) | 1.32 |
Duration | Duration | 1:15:18 | |
MinCurrent | min. Current | 0.439 | A |
MaxCurrent | max. Current | 0.477 | A |
Duration | Duration | 1:15:18 | |
MinCurrent | min. Current | 0.365 | A |
MaxCurrent | max. Current | 0.387 | A |
ModuleIa | Module Ia | 382.7 | mA |
Temperature | Temp. while test | 17.00 +/- 0.08 | °C |
Duration | Duration of test | 0:09:15 |
ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chip 0 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
128.91
|
1756 |
53
|
0.028
|
1420
|
Chip 1 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
136.34
|
1754 |
55
|
0.024
|
1196
|
Chip 2 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
123.26
|
1754 |
53
|
0.032
|
1064
|
Chip 3 |
A
|
19
|
0
|
0
|
0
|
0
|
0
|
0
|
19
|
0
|
0
|
0
|
128.04
|
1754 |
62
|
0.031
|
1052
|
Chip 4 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
137.68
|
1755 |
56
|
0.033
|
1128
|
Chip 5 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
130.56
|
1755 |
50
|
0.036
|
1244
|
Chip 6 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
124.03
|
1755 |
50
|
0.029
|
970
|
Chip 7 |
A
|
32
|
3
|
0
|
29
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
130.36
|
1753 |
53
|
0.036
|
1365
|
Chip 8 |
A
|
3
|
0
|
0
|
3
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
133.94
|
1754 |
53
|
0.032
|
1222
|
Chip 9 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
128.41
|
1754 |
50
|
0.038
|
935
|
Chip 10 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
134.58
|
1754 |
53
|
0.032
|
1201
|
Chip 11 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
131.99
|
1755 |
56
|
0.031
|
1418
|
Chip 12 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
0
|
136.78
|
1754 |
57
|
0.028
|
1324
|
Chip 13 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
134.43
|
1757 |
53
|
0.034
|
1154
|
Chip 14 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
128.02
|
1754 |
52
|
0.033
|
1131
|
Chip 15 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
130.42
|
1758 |
57
|
0.036
|
1188
|
ModifiedGrading | Modified Grading | True | |
GradingParameters_leakageCurrentRatioB | leakageCurrentRatioB | 20 => -111 |
nTBMs | n | 1 | |
TBMType | Type | tbm09c | |
Core0a_basea | Core 0a base a | 0x40 | |
Core0a_basee | Core 0a base e | 0x6c | |
Core0b_basea | Core 0b base a | 0x49 | |
Core0b_basee | Core 0b base e | 0x00 | |
RocDelay_Ch0 | Roc Delay Ch0 | 0 | |
RocDelay_Ch1 | Roc Delay Ch1 | 0 | |
RocDelay_Ch2 | Roc Delay Ch2 | 1 | |
RocDelay_Ch3 | Roc Delay Ch3 | 1 | |
Phase400 | Phase 400 | 3 | |
Phase160 | Phase 160 | 3 |
nCriticals | # Criticals | 2 | |
nErrors | # Errors | 8412 | |
nWarnings | # Warnings | 1206 | |
channel_0_count | Channel 0 | 0 | |
channel_1_count | Channel 1 | 0 | |
channel_2_count | Channel 2 | 8830 | |
channel_3_count | Channel 3 | 788 | |
message_eventid_count | Event ID mismatch | 2605 | |
message_readback_count | Readback start marker | 1206 | |
message_tokenchain_count | Token Chain Length | 5807 | |
message_missingevents_count | Missing Event criticals | 2 |
