Test Date: 2016-11-07 16:36
Analysis date: 2016-11-07 17:21
Analysis date: 2016-11-07 17:21
M1125 XRayHRQualification
Summary
| Module | Module | M1125 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 4 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.57 | % |
| Noise | Mean Noise | 335 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.58 | 0.27 | 220.0 | 0 | 70.2 | 0/0 | 0 | 3708 | 349 | 1005 |
|
Chip 1
|
A
|
0 | 0 | 99.82 | 99.57 | 0.36 | 227.7 | 0 | 73.3 | 0/0 | 0 | 3634 | 377 | 1429 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.59 | 0.25 | 197.8 | 0 | 64.3 | 0/0 | 0 | 3693 | 349 | 1047 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.62 | 0.21 | 143.3 | 0 | 47.0 | 0/0 | 0 | 3719 | 326 | 773 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.77 | 0.22 | 115.8 | 0 | 38.1 | 0/0 | 0 | 3788 | 304 | 401 |
|
Chip 5
|
A
|
1 | 0 | 99.83 | 99.58 | 0.18 | 129.7 | 0 | 42.0 | 0/0 | 0 | 3822 | 298 | 402 |
|
Chip 6
|
A
|
0 | 0 | 99.82 | 99.45 | 0.27 | 157.8 | 0 | 51.5 | 0/0 | 0 | 3693 | 361 | 1210 |
|
Chip 7
|
A
|
1 | 0 | 99.79 | 99.70 | 0.24 | 149.9 | 0 | 49.0 | 0/0 | 0 | 3727 | 345 | 947 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.58 | 0.35 | 129.2 | 0 | 42.2 | 0/0 | 0 | 3783 | 323 | 639 |
|
Chip 9
|
A
|
0 | 0 | 99.84 | 99.30 | 0.23 | 112.0 | 0 | 36.8 | 0/0 | 0 | 3823 | 289 | 288 |
|
Chip 10
|
A
|
0 | 0 | 99.83 | 99.64 | 0.24 | 151.2 | 0 | 49.4 | 0/0 | 0 | 3678 | 334 | 846 |
|
Chip 11
|
A
|
1 | 0 | 99.84 | 99.53 | 0.2 | 114.2 | 1 | 37.5 | 0/0 | 0 | 3788 | 298 | 395 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.62 | 0.25 | 116.9 | 0 | 38.6 | 0/0 | 0 | 3741 | 319 | 676 |
|
Chip 13
|
A
|
0 | 0 | 99.82 | 99.54 | 0.29 | 198.4 | 0 | 64.6 | 0/0 | 0 | 3658 | 368 | 1269 |
|
Chip 14
|
A
|
0 | 0 | 99.82 | 99.53 | 0.3 | 188.2 | 0 | 60.9 | 0/0 | 0 | 3655 | 364 | 1216 |
|
Chip 15
|
A
|
1 | 0 | 99.81 | 99.54 | 0.52 | 214.7 | 0 | 69.1 | 0/0 | 0 | 3709 | 362 | 1217 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-07 | |
| TestTime | Test Time | 16:36 | |
| TestDuration | Duration | 0:36:56 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
v1.1.1-1-g54fa876 on branch master
