Test Date: 2016-11-14 17:33
Analysis date: 2016-11-14 18:19
Analysis date: 2016-11-14 18:19
M1060 XRayHRQualification
Summary
| Module | Module | M1060 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 150/300 | 99.82/99.58 | % |
| Noise | Mean Noise | 383 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 150 | Eff 300 | Eff chi2 | Rate "300" | BB def | Rate "100" | R/O | Unif. | Thr [e-] "250" | Noise "250" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 99.57 | 0.23 | 262.0 | 0 | 85.2 | 0/0 | 0 | 3618 | 404 | 1831 |
|
Chip 1
|
A
|
0 | 0 | 99.83 | 99.56 | 0.29 | 245.9 | 0 | 79.4 | 0/0 | 0 | 3625 | 400 | 1785 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 99.57 | 0.33 | 227.9 | 0 | 74.4 | 0/0 | 0 | 3633 | 382 | 1530 |
|
Chip 3
|
A
|
0 | 0 | 99.82 | 99.57 | 0.22 | 160.6 | 0 | 52.7 | 0/0 | 0 | 3659 | 380 | 1465 |
|
Chip 4
|
A
|
0 | 0 | 99.81 | 99.58 | 0.24 | 157.6 | 0 | 52.3 | 0/0 | 0 | 3610 | 400 | 1795 |
|
Chip 5
|
A
|
0 | 0 | 99.82 | 99.59 | 0.22 | 195.6 | 0 | 63.9 | 0/0 | 0 | 3597 | 392 | 1636 |
|
Chip 6
|
A
|
0 | 0 | 99.81 | 99.64 | 0.29 | 175.4 | 0 | 57.6 | 0/0 | 0 | 3619 | 387 | 1547 |
|
Chip 7
|
A
|
0 | 0 | 99.83 | 99.72 | 0.25 | 164.0 | 0 | 54.3 | 0/0 | 0 | 3653 | 363 | 1251 |
|
Chip 8
|
A
|
0 | 0 | 99.81 | 99.46 | 0.26 | 160.4 | 0 | 52.9 | 0/0 | 0 | 3714 | 351 | 1126 |
|
Chip 9
|
A
|
0 | 0 | 99.84 | 99.64 | 0.18 | 133.5 | 0 | 44.2 | 0/0 | 0 | 3741 | 319 | 643 |
|
Chip 10
|
A
|
0 | 0 | 99.82 | 99.54 | 0.28 | 185.1 | 0 | 61.1 | 0/0 | 0 | 3570 | 410 | 1937 |
|
Chip 11
|
A
|
0 | 0 | 99.80 | 99.50 | 0.25 | 141.1 | 0 | 47.1 | 0/0 | 0 | 3636 | 365 | 1260 |
|
Chip 12
|
A
|
0 | 0 | 99.81 | 99.59 | 0.25 | 143.5 | 0 | 47.6 | 0/0 | 0 | 3638 | 380 | 1460 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 99.58 | 0.27 | 207.3 | 0 | 68.3 | 0/0 | 0 | 3590 | 386 | 1541 |
|
Chip 14
|
A
|
0 | 0 | 99.81 | 99.56 | 0.32 | 243.6 | 0 | 80.1 | 0/0 | 0 | 3551 | 428 | 2155 |
|
Chip 15
|
A
|
0 | 0 | 99.82 | 99.55 | 0.33 | 251.7 | 0 | 80.4 | 0/0 | 0 | 3435 | 377 | 1462 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-11-14 | |
| TestTime | Test Time | 17:33 | |
| TestDuration | Duration | 0:37:44 | |
| pXar | pXar version | v2.7.6+59~gd48421b | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 14 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
