Test Date: 2015-12-11 15:01
Analysis date: 2015-12-15 09:49
Analysis date: 2015-12-15 09:49
M4077 XRayHRQualification
Summary
| Module | Module | M4077 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.12 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.86 | 98.90 | 1.18 | 26.2 | 90.3 | 0 | 0/0 | 0 | 1966 | 166 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.86 | 99.27 | 0.60 | 28.8 | 99.0 | 0 | 0/0 | 0 | 2005 | 171 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 98.93 | 1.98 | 25.7 | 89.6 | 0 | 0/0 | 0 | 1965 | 159 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.83 | 99.01 | 0.68 | 46.4 | 153.0 | 0 | 0/0 | 0 | 2126 | 171 | 0 |
|
Chip 4
|
A
|
2 | 0 | 99.86 | 99.22 | 0.93 | 47.8 | 158.2 | 2 | 0/0 | 0 | 2126 | 164 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.86 | 99.28 | 0.73 | 57.6 | 187.2 | 0 | 0/0 | 0 | 2182 | 163 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.85 | 99.02 | 0.69 | 53.6 | 176.6 | 0 | 0/0 | 0 | 2152 | 154 | 0 |
|
Chip 7
|
A
|
1 | 0 | 99.87 | 99.23 | 0.70 | 60.4 | 197.8 | 1 | 0/0 | 0 | 2187 | 162 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.84 | 98.99 | 0.87 | 55.8 | 184.2 | 0 | 0/0 | 0 | 2152 | 161 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.85 | 99.22 | 1.25 | 52.0 | 171.6 | 0 | 0/0 | 0 | 2163 | 164 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.86 | 99.18 | 1.88 | 55.1 | 179.6 | 0 | 0/0 | 0 | 2174 | 165 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.28 | 0.52 | 45.7 | 152.1 | 0 | 0/0 | 0 | 2120 | 164 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.32 | 0.51 | 42.4 | 140.8 | 0 | 0/0 | 0 | 2096 | 173 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.21 | 0.96 | 24.7 | 86.4 | 0 | 0/0 | 0 | 1991 | 165 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 98.94 | 0.99 | 26.8 | 93.2 | 0 | 0/0 | 0 | 1976 | 165 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 98.88 | 1.09 | 25.9 | 88.7 | 0 | 0/0 | 0 | 2019 | 169 | 0 |
Errors
| nCriticals | # Criticals | 2 | |
| nErrors | # Errors | 45 | |
| nWarnings | # Warnings | 4 | |
| channel_0_count | Channel 0 | 6 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 4 | |
| message_notokenpass_count | has NoTokenPass | 2 | |
| message_datasize_count | Data size criticals | 1 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
