Test Date: 2016-07-28 13:42
Analysis date: 2016-07-28 14:14
Analysis date: 2016-07-28 14:14
Chip 8
Pixel Map: C8
| NNotAlivePixels | Tot. Dead Pixels | 5 | |
| NDeadPixels | - N Dead Pixels | 5 | |
| NNoisyPixels | - N Noisy Pixels | 0 | |
| NMaskDefects | - N Mask Defects | 0 | |
| NInefficentPixels | - N Inefficent Pixels | 0 |
Address Decoding: C8
Bump Bonding: C8
| Mean | Mean | 46.73 | |
| RMS | RMS | 6.1 | |
| Threshold | Threshold | 78.0 | |
| nSigma | σ | 5.0 | |
| nBumpBondingProblems | N BumpProblems | 4.0 | |
| nBumpBondingProblemsOld | N (old cut) | 1 |
Iana [ADC]/Iana [mA]
| FitFunction | fit | [0]+[1]*x+[2]*x**2 | |
| par0ia | par0ia | -6.524e+00 | |
| par1ia | par1ia | 3.888e+00 | |
| par2ia | par2ia | 2.417e-02 | |
| chi2ia | chi2/ndf | 1.71 |
Vdig [ADC]/Vdig [V]
| FitFunction | fit | [0]+[1]*x | |
| par0vd | par0vd | -2.171e-01 | |
| par1vd | par1vd | 6.035e+01 | |
| chi2vd | chi2/ndf | 0.2 |
Vana [ADC]/Vana [V]
| FitFunction | fit | [0]+[1]*x | |
| par0va | par0va | -7.140e+00 | |
| par1va | par1va | 6.281e+01 | |
| chi2va | chi2/ndf | 0.34 |
ReadbackCal
| par0vd | par0vd | -2.17e-01 | |
| par1vd | par1vd | 6.03e+01 | |
| par0va | par0va | -7.14e+00 | |
| par1va | par1va | 6.28e+01 | |
| par0rbia | par0rbia | 1.06e+01 | |
| par1rbia | par1rbia | 1.05e+00 | |
| par0tbia | par0tbia | 4.71e+00 | |
| par1tbia | par1tbia | 2.37e-01 | |
| par2tbia | par2tbia | -1.58e-04 | |
| Vbg | Vbg | 1.23 | |
| par0ia | par0ia | -6.524e+00 | |
| par1ia | par1ia | 3.888e+00 | |
| par2ia | par2ia | 2.417e-02 | |
| ReadbackCalibrated | Calibrated | True |
