Chip 13
Pixel Map: C13
| NNotAlivePixels | Tot. Dead Pixels | 0 | |
| NDeadPixels | - N Dead Pixels | 0 | |
| NNoisyPixels | - N Noisy Pixels | 0 | |
| NMaskDefects | - N Mask Defects | 0 | |
| NInefficentPixels | - N Inefficent Pixels | 0 |
Address Decoding: C13
Bump Bonding: C13
| Mean | Mean | 42.67 | |
| RMS | RMS | 8.27 | |
| Threshold | Threshold | 85.0 | |
| nSigma | σ | 5.0 | |
| nBumpBondingProblems | N BumpProblems | 0.0 | |
| nBumpBondingProblemsOld | N (old cut) | 1 |
Iana [ADC]/Iana [mA]
| FitFunction | fit | [0]+[1]*x+[2]*x**2 | |
| par0ia | par0ia | -2.236e+00 | |
| par1ia | par1ia | 3.628e+00 | |
| par2ia | par2ia | 2.041e-02 | |
| chi2ia | chi2/ndf | 11.35 |
Vdig [ADC]/Vdig [V]
| FitFunction | fit | [0]+[1]*x | |
| par0vd | par0vd | -5.056e+00 | |
| par1vd | par1vd | 6.581e+01 | |
| chi2vd | chi2/ndf | 0.55 |
Vana [ADC]/Vana [V]
| FitFunction | fit | [0]+[1]*x | |
| par0va | par0va | -2.322e+00 | |
| par1va | par1va | 6.437e+01 | |
| chi2va | chi2/ndf | 0.29 |
ReadbackCal
| par0vd | par0vd | -5.06e+00 | |
| par1vd | par1vd | 6.58e+01 | |
| par0va | par0va | -2.32e+00 | |
| par1va | par1va | 6.44e+01 | |
| par0rbia | par0rbia | 1.60e+01 | |
| par1rbia | par1rbia | 1.08e+00 | |
| par0tbia | par0tbia | 4.77e+00 | |
| par1tbia | par1tbia | 2.77e-01 | |
| par2tbia | par2tbia | -2.44e-04 | |
| Vbg | Vbg | 1.218 | |
| par0ia | par0ia | -2.236e+00 | |
| par1ia | par1ia | 3.628e+00 | |
| par2ia | par2ia | 2.041e-02 | |
| ReadbackCalibrated | Calibrated | True |
