Test Date: 2015-10-27 09:40
Analysis date: 2015-10-27 10:42
Analysis date: 2015-10-27 10:42
M3022 XRayHRQualification
Summary
| Module | Module | M3022 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 22 | |
| BumpBondingDefects | Bump Bonding Defects | 10 | |
| NoisyPixels | Noisy Pixels | 12 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.18 | % |
| Noise | Mean Noise | 174 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | RO prob | Unif. prob | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.83 | 98.99 | 0.71 | 17.5 | 58.8 | 0 | 0/0 | 0 | 1928 | 167 | 0 |
|
Chip 1
|
A
|
0 | 99.86 | 99.23 | 0.46 | 18.6 | 63.5 | 0 | 0/0 | 0 | 1944 | 179 | 0 |
|
Chip 2
|
A
|
1 | 99.86 | 99.28 | 0.38 | 17.0 | 58.9 | 0 | 0/0 | 0 | 1868 | 180 | 1 |
|
Chip 3
|
A
|
1 | 99.87 | 99.28 | 1.47 | 29.4 | 96.8 | 1 | 0/0 | 0 | 2009 | 183 | 0 |
|
Chip 4
|
A
|
0 | 99.86 | 99.02 | 0.52 | 29.8 | 99.1 | 0 | 0/0 | 0 | 2020 | 170 | 0 |
|
Chip 5
|
A
|
3 | 99.86 | 99.05 | 0.60 | 37.8 | 121.8 | 3 | 0/0 | 0 | 2092 | 182 | 0 |
|
Chip 6
|
A
|
5 | 99.85 | 99.28 | 0.62 | 36.1 | 117.5 | 1 | 0/0 | 0 | 1958 | 175 | 4 |
|
Chip 7
|
A
|
4 | 99.88 | 99.30 | 0.53 | 38.9 | 126.0 | 0 | 0/0 | 0 | 1932 | 171 | 4 |
|
Chip 8
|
A
|
4 | 99.86 | 99.08 | 0.73 | 38.3 | 124.3 | 2 | 0/0 | 0 | 1999 | 179 | 2 |
|
Chip 9
|
A
|
0 | 99.87 | 99.28 | 0.97 | 33.6 | 110.4 | 0 | 0/0 | 0 | 2058 | 167 | 0 |
|
Chip 10
|
A
|
1 | 99.86 | 99.35 | 0.42 | 36.4 | 117.7 | 0 | 0/0 | 0 | 2012 | 180 | 1 |
|
Chip 11
|
A
|
0 | 99.87 | 99.26 | 0.92 | 29.5 | 97.3 | 0 | 0/0 | 0 | 2024 | 168 | 0 |
|
Chip 12
|
A
|
0 | 99.84 | 99.02 | 0.82 | 27.2 | 90.1 | 0 | 0/0 | 0 | 1998 | 172 | 0 |
|
Chip 13
|
A
|
2 | 99.85 | 99.28 | 0.40 | 16.6 | 57.1 | 2 | 0/0 | 0 | 1942 | 174 | 0 |
|
Chip 14
|
A
|
0 | 99.84 | 98.94 | 0.47 | 17.3 | 59.6 | 0 | 0/0 | 0 | 1912 | 170 | 0 |
|
Chip 15
|
A
|
1 | 99.85 | 99.22 | 0.73 | 17.2 | 57.7 | 1 | 0/0 | 0 | 1926 | 171 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
