Test Date: 2015-10-29 13:58
Analysis date: 2015-10-30 19:00
Analysis date: 2015-10-30 19:00
M3022 ModuleFulltestPxar_p17_1
Summary 1
| Module | Module | M3022 | |
| Grade | Grade | A | |
| ElectricalGrade | Electrical Grade | A | |
| IVGrade | IV Grade | A | |
| ManualGrade | Manual Grade | None | |
| PixelDefects | Pixel Defects - A/B/C | 39 - 16/0/0 | |
| DeadPixels | Dead Pixels | 14 | |
| AddressProblems | Address Problems | 0 | |
| ThresholdDefects | Threshold Defects | 4 | |
| MaskDefects | Mask Defects | 0 | |
| DeadBumps | Dead Bumps | 21 | |
| NoisyPixels | Noise Defects | 0 | |
| TrimProblems | Trim Problems | 3 | |
| PHGainDefects | PH Gain Defects | 4 | |
| PHPedestalDefects | PH Pedestal Defects | 0 | |
| PHPar1Defects | PH Parameter1 Defects | 15 |
Summary 2
| TestCenter | Test Center | ETH | |
| TestDate | Test Date | 2015-10-29 | |
| TestTime | Test Time | 13:58 | |
| TestDuration | Test Duration | 1:15:08 | |
| TempC | Temparature | 17 | °C |
| TrimPHCal | Trim / phCal | yes / yes | |
| TermCycl | Term. Cycl. | yes | |
| TBM1 | TBM1 | ok, 0xe8 0xe4 | |
| TBM2 | TBM2 | ok, 0x00 0xe4 | |
| PxarVersion | pXar | v2.6.0+26 g89693ff | |
| ModuleIa | Module Ia | 388.3 | mA |
Summary 3
| Noise | Noise | 142.42 | e |
| NoiseROCs | Noise grades | 16/0/0 | |
| VcalThrWidth | Vcal Thr. Width | 46.50 | e |
| VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
| RelGainWidth | Rel. Gain Width | 0.03 | % |
| RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
| PedestalSpread | Pedestal Spread | 1198.09 | e |
| PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
| Parameter1 | Parameter1 | 0.67 | |
| Parameter1ROCs | Par1 grades | 16/0/0 | |
| CurrentAtVoltage150V | I(150 V) | 0.60 | μA |
| CurrentVariation | I(150 V) / I(100 V) | 1.13 |
IVCurve
Digital Current
| Duration | Duration | 1:15:08 | |
| MinCurrent | min. Current | 0.359 | A |
| MaxCurrent | max. Current | 0.468 | A |
Analog Current
| Duration | Duration | 1:15:08 | |
| MinCurrent | min. Current | 0.073 | A |
| MaxCurrent | max. Current | 0.392 | A |
| ModuleIa | Module Ia | 388.3 | mA |
IanaLoss
| IanaLossProblems | Iana problems | No | |
| Mean | mean | 19.30 | |
| Min | min | 18.50 | |
| Max | max | 20.10 |
Temperature
| Temperature | Temp. while test | 17.00 +/- 0.07 | °C |
| Duration | Duration of test | 1:15:13 |
Summary ROCs
| ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Chip 0 |
A
|
3
|
0
|
0
|
3
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
138.42
|
1746 |
44
|
0.031
|
1030
|
| Chip 1 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
141.01
|
1748 |
48
|
0.031
|
1324
|
| Chip 2 |
A
|
1
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
134.15
|
1748 |
48
|
0.037
|
1278
|
| Chip 3 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
1
|
154.49
|
1748 |
48
|
0.031
|
1540
|
| Chip 4 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
145.06
|
1748 |
45
|
0.028
|
1071
|
| Chip 5 |
A
|
3
|
0
|
0
|
3
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
152.82
|
1749 |
47
|
0.033
|
1322
|
| Chip 6 |
A
|
5
|
4
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
4
|
146.52
|
1752 |
46
|
0.034
|
1093
|
| Chip 7 |
A
|
6
|
4
|
0
|
2
|
1
|
0
|
0
|
0
|
1
|
0
|
4
|
148.53
|
1750 |
47
|
0.033
|
1196
|
| Chip 8 |
A
|
6
|
3
|
0
|
3
|
0
|
0
|
0
|
0
|
0
|
0
|
3
|
151.42
|
1749 |
47
|
0.035
|
1080
|
| Chip 9 |
A
|
2
|
1
|
0
|
1
|
1
|
0
|
0
|
0
|
2
|
0
|
0
|
131.00
|
1750 |
46
|
0.030
|
1212
|
| Chip 10 |
A
|
1
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
138.66
|
1748 |
49
|
0.033
|
1452
|
| Chip 11 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
133.98
|
1749 |
46
|
0.037
|
1161
|
| Chip 12 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
137.49
|
1748 |
46
|
0.030
|
1011
|
| Chip 13 |
A
|
3
|
0
|
0
|
2
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
143.08
|
1749 |
46
|
0.032
|
1249
|
| Chip 14 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
139.11
|
1750 |
44
|
0.031
|
1105
|
| Chip 15 |
A
|
5
|
0
|
0
|
4
|
1
|
0
|
0
|
1
|
1
|
0
|
1
|
143.02
|
1748 |
47
|
0.041
|
1047
|
TBM
| nTBMs | n | 1 | |
| TBMType | Type | tbm08c | |
| Core0a_basea | Core 0a base a | 0xe4 | |
| Core0a_basee | Core 0a base e | 0xe8 | |
| Core0b_basea | Core 0b base a | 0xe4 | |
| Core0b_basee | Core 0b base e | 0x00 | |
| RocDelay_Ch0 | Roc Delay Ch0 | 4 | |
| RocDelay_Ch1 | Roc Delay Ch1 | 4 | |
| RocDelay_Ch2 | Roc Delay Ch2 | 4 | |
| RocDelay_Ch3 | Roc Delay Ch3 | 4 | |
| Phase400 | Phase 400 | 2 | |
| Phase160 | Phase 160 | 7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 2 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 2 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 | |
| message_eventid_count | Event ID mismatch | 1 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
GradingParameters
| ModifiedGrading | Modified Grading | False |
MoReWeb-v0.6.7-20-g27c4078
on branch compareCenters
