Test Date: 2015-10-27 11:11
Analysis date: 2015-10-27 13:37
Analysis date: 2015-10-27 13:37
M3021 XRayHRQualification
Summary
| Module | Module | M3021 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 28 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 24 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.15 | % |
| Noise | Mean Noise | 170 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | RO prob | Unif. prob | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 99.88 | 99.13 | 0.45 | 17.1 | 57.3 | 0 | 0/0 | 0 | 1885 | 167 | 1 |
|
Chip 1
|
A
|
1 | 99.87 | 99.27 | 0.34 | 17.3 | 59.4 | 1 | 0/0 | 0 | 1933 | 166 | 0 |
|
Chip 2
|
A
|
1 | 99.86 | 99.05 | 0.32 | 15.2 | 53.2 | 1 | 0/0 | 0 | 1901 | 156 | 0 |
|
Chip 3
|
A
|
0 | 99.85 | 99.02 | 0.68 | 27.3 | 90.5 | 0 | 0/0 | 0 | 2016 | 171 | 0 |
|
Chip 4
|
A
|
0 | 99.82 | 98.98 | 1.77 | 31.1 | 102.4 | 0 | 0/0 | 0 | 1978 | 201 | 0 |
|
Chip 5
|
A
|
1 | 99.88 | 99.29 | 0.81 | 34.7 | 113.2 | 1 | 0/0 | 0 | 2038 | 174 | 0 |
|
Chip 6
|
A
|
2 | 99.82 | 98.96 | 0.89 | 32.9 | 108.5 | 1 | 0/0 | 0 | 1999 | 167 | 1 |
|
Chip 7
|
A
|
4 | 99.86 | 99.21 | 0.41 | 36.4 | 119.3 | 0 | 0/0 | 0 | 1914 | 166 | 4 |
|
Chip 8
|
A
|
4 | 99.87 | 99.29 | 0.43 | 37.2 | 121.4 | 0 | 0/0 | 0 | 1933 | 167 | 4 |
|
Chip 9
|
A
|
2 | 99.86 | 98.96 | 0.69 | 32.5 | 107.3 | 0 | 0/0 | 0 | 1959 | 168 | 2 |
|
Chip 10
|
A
|
1 | 99.88 | 99.33 | 0.49 | 34.3 | 111.9 | 0 | 0/0 | 0 | 2003 | 169 | 1 |
|
Chip 11
|
A
|
0 | 99.88 | 99.29 | 0.66 | 28.8 | 95.8 | 0 | 0/0 | 0 | 2014 | 178 | 0 |
|
Chip 12
|
A
|
0 | 99.88 | 99.27 | 1.28 | 25.8 | 85.9 | 0 | 0/0 | 0 | 2002 | 157 | 0 |
|
Chip 13
|
A
|
3 | 99.84 | 99.00 | 0.27 | 15.3 | 53.3 | 0 | 0/0 | 0 | 1820 | 154 | 3 |
|
Chip 14
|
A
|
0 | 99.88 | 99.29 | 0.35 | 17.1 | 58.6 | 0 | 0/0 | 0 | 1924 | 172 | 0 |
|
Chip 15
|
A
|
8 | 99.86 | 99.01 | 0.46 | 17.6 | 58.7 | 0 | 0/0 | 0 | 1625 | 184 | 8 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 3 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
