Test Date: 2015-10-01 11:49
Analysis date: 2015-10-26 20:00
Analysis date: 2015-10-26 20:00
M3021 XRayHRQualification
Summary
| Module | Module | M3021 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 4 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 1 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.11 | % |
| Noise | Mean Noise | 163 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | RO prob | Unif. prob | Thr [e-] "10" | Noise "10" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.84 | 99.00 | 0.40 | 45.0 | 114.0 | 0 | 0/0 | 0 | 1772 | 156 | 0 |
|
Chip 1
|
A
|
1 | 99.84 | 99.08 | 0.69 | 46.0 | 116.5 | 1 | 0/0 | 0 | 1781 | 159 | 0 |
|
Chip 2
|
A
|
1 | 99.86 | 99.30 | 0.42 | 38.6 | 97.8 | 1 | 0/0 | 0 | 1752 | 150 | 0 |
|
Chip 3
|
A
|
0 | 99.88 | 99.28 | 0.42 | 63.8 | 161.0 | 0 | 0/0 | 0 | 1791 | 167 | 0 |
|
Chip 4
|
A
|
0 | 99.82 | 99.04 | 1.97 | 67.0 | 169.5 | 0 | 0/0 | 0 | 1755 | 191 | 0 |
|
Chip 5
|
A
|
1 | 99.91 | 99.26 | 1.49 | 73.1 | 184.2 | 1 | 0/0 | 0 | 1782 | 169 | 0 |
|
Chip 6
|
A
|
1 | 99.78 | 99.02 | 0.79 | 67.1 | 168.6 | 1 | 0/0 | 0 | 1830 | 155 | 0 |
|
Chip 7
|
A
|
0 | 99.82 | 98.98 | 1.49 | 73.1 | 183.9 | 0 | 0/0 | 0 | 1770 | 161 | 0 |
|
Chip 8
|
A
|
0 | 99.84 | 99.01 | 1.26 | 74.8 | 188.7 | 0 | 0/0 | 0 | 1826 | 166 | 0 |
|
Chip 9
|
A
|
0 | 99.85 | 99.29 | 0.53 | 69.2 | 174.6 | 0 | 0/0 | 0 | 1786 | 160 | 0 |
|
Chip 10
|
A
|
1 | 99.88 | 99.31 | 0.34 | 74.7 | 188.3 | 0 | 0/0 | 0 | 1799 | 166 | 0 |
|
Chip 11
|
A
|
0 | 99.85 | 98.98 | 0.53 | 66.4 | 167.7 | 0 | 0/0 | 0 | 1794 | 170 | 0 |
|
Chip 12
|
A
|
0 | 99.85 | 99.13 | 0.87 | 62.8 | 158.1 | 0 | 0/0 | 0 | 1818 | 151 | 0 |
|
Chip 13
|
A
|
0 | 99.85 | 99.11 | 0.50 | 40.6 | 102.3 | 0 | 0/0 | 0 | 1777 | 144 | 0 |
|
Chip 14
|
A
|
0 | 99.84 | 99.00 | 0.60 | 47.5 | 120.1 | 0 | 0/0 | 0 | 1771 | 166 | 0 |
|
Chip 15
|
A
|
0 | 99.85 | 99.04 | 0.65 | 48.2 | 122.0 | 0 | 0/0 | 0 | 1747 | 174 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.6.7-11-ga66536c
on branch psi46master
