Test Date: 2015-10-01 11:49
Analysis date: 2015-10-26 19:54
X-ray Calibration - Spectrum
| Slope |
avrg Slope |
52.139625 |
|
Chips_Xray
Overview
Slope of Spectrum Vcal Calibration
| avrgSlope |
avrg Slope |
52.139625 |
|
| medianSlope |
median Slope |
52.598 |
|
| minSlope |
min Slope |
48.615 |
|
| maxSlope |
max Slope |
55.912 |
|
Offset of Spectrum Vcal Calibration
| avrgOffset |
avrg Offset |
-112.4409375 |
|
| medianOffset |
median Offset |
-95.852 |
|
| minOffset |
min Offset |
-569.278 |
|
| maxOffset |
max Offset |
231.205 |
|
Chi2 of Spectrum Vcal Calibration
| avrgchi2 |
avrg chi2 |
2.981375 |
|
| medianchi2 |
median chi2 |
0.515 |
|
| minchi2 |
min chi2 |
0.008 |
|
| maxchi2 |
max chi2 |
14.938 |
|
Vcal Calibration Module - Spectrum
|
ROC
|
Slope
|
Slope Error
|
Offset
|
Offset Error
|
|
0
|
54.5 e- / Vcal
|
0.2 e- / Vcal
|
-66.2 e-
|
12.4 e-
|
|
1
|
50.0 e- / Vcal
|
0.2 e- / Vcal
|
-55.3 e-
|
18.2 e-
|
|
2
|
52.8 e- / Vcal
|
0.2 e- / Vcal
|
-27.0 e-
|
12.3 e-
|
|
3
|
55.5 e- / Vcal
|
1.5 e- / Vcal
|
-569.3 e-
|
148.2 e-
|
|
4
|
53.9 e- / Vcal
|
0.1 e- / Vcal
|
-213.9 e-
|
11.0 e-
|
|
5
|
53.0 e- / Vcal
|
0.1 e- / Vcal
|
-224.0 e-
|
8.4 e-
|
|
6
|
51.9 e- / Vcal
|
0.1 e- / Vcal
|
-179.3 e-
|
9.6 e-
|
|
7
|
52.5 e- / Vcal
|
0.1 e- / Vcal
|
-123.5 e-
|
8.7 e-
|
|
8
|
49.2 e- / Vcal
|
0.3 e- / Vcal
|
155.8 e-
|
37.4 e-
|
|
9
|
51.9 e- / Vcal
|
0.1 e- / Vcal
|
-117.1 e-
|
10.2 e-
|
|
10
|
50.1 e- / Vcal
|
0.1 e- / Vcal
|
-242.3 e-
|
10.8 e-
|
|
11
|
48.6 e- / Vcal
|
0.6 e- / Vcal
|
-3.2 e-
|
64.0 e-
|
|
12
|
52.9 e- / Vcal
|
0.1 e- / Vcal
|
-74.6 e-
|
9.7 e-
|
|
13
|
48.7 e- / Vcal
|
0.4 e- / Vcal
|
231.2 e-
|
48.5 e-
|
|
14
|
52.7 e- / Vcal
|
0.1 e- / Vcal
|
-34.1 e-
|
11.2 e-
|
|
15
|
55.9 e- / Vcal
|
0.3 e- / Vcal
|
-256.4 e-
|
29.6 e-
|
|
Average
|
52.1 e- / Vcal
|
|
-112.4 e-
|
|
|
Median
|
52.7 e- / Vcal
|
|
-74.6 e-
|
|
Overview
Xray Module Spectrum - Zn
Overview
Xray Module Spectrum - Mo
Overview
Xray Module Spectrum - Ag
Overview
Xray Module Spectrum - Sn
Overview
Hits distribution Zn inner/edge/corner
Hits distribution Mo inner/edge/corner
Hits distribution Ag inner/edge/corner
Hits distribution Sn inner/edge/corner
