Test Date: 2015-07-27 09:56
Analysis date: 2015-10-28 14:48
Analysis date: 2015-10-28 14:48
M3015 ModuleFulltest_p17_1
Summary 1
| Module | Module | M3015 | |
| Grade | Grade | A | |
| ElectricalGrade | Electrical Grade | A | |
| IVGrade | IV Grade | A | |
| ManualGrade | Manual Grade | None | |
| PixelDefects | Pixel Defects - A/B/C | 43 - 16/0/0 | |
| DeadPixels | Dead Pixels | 4 | |
| AddressProblems | Address Problems | 0 | |
| ThresholdDefects | Threshold Defects | 18 | |
| MaskDefects | Mask Defects | 0 | |
| DeadBumps | Dead Bumps | 20 | |
| NoisyPixels | Noise Defects | 0 | |
| TrimProblems | Trim Problems | 1 | |
| PHGainDefects | PH Gain Defects | 4 | |
| PHPedestalDefects | PH Pedestal Defects | 0 | |
| PHPar1Defects | PH Parameter1 Defects | 12 |
Summary 2
| TestCenter | Test Center | CERN | |
| TestDate | Test Date | 2015-07-27 | |
| TestTime | Test Time | 09:56 | |
| TestDuration | Test Duration | 1:01:07 | |
| TempC | Temparature | 17 | °C |
| TrimPHCal | Trim / phCal | yes / yes | |
| TermCycl | Term. Cycl. | yes | |
| TBM1 | TBM1 | ok, 0x30 0xf6 | |
| TBM2 | TBM2 | ok, 0x00 0xf6 | |
| PxarVersion | pXar | v2.2.5+67 g3b1c276 | |
| ModuleIa | Module Ia | 379.4 | mA |
Summary 3
| Noise | Noise | 145.31 | e |
| NoiseROCs | Noise grades | 16/0/0 | |
| VcalThrWidth | Vcal Thr. Width | 58.59 | e |
| VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
| RelGainWidth | Rel. Gain Width | 0.03 | % |
| RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
| PedestalSpread | Pedestal Spread | 1203.66 | e |
| PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
| Parameter1 | Parameter1 | 0.70 | |
| Parameter1ROCs | Par1 grades | 16/0/0 | |
| CurrentAtVoltage150V | I(150 V) | 0.33 | μA |
| CurrentVariation | I(150 V) / I(100 V) | 1.04 |
IVCurve
Digital Current
| Duration | Duration | 1:01:07 | |
| MinCurrent | min. Current | 0.431 | A |
| MaxCurrent | max. Current | 0.469 | A |
Analog Current
| Duration | Duration | 1:01:07 | |
| MinCurrent | min. Current | 0.359 | A |
| MaxCurrent | max. Current | 0.382 | A |
| ModuleIa | Module Ia | 379.4 | mA |
Temperature
| Temperature | Temp. while test | 16.73 +/- 0.26 | °C |
| Duration | Duration of test | 0:05:16 |
Summary ROCs
| ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Chip 0 |
A
|
4
|
0
|
0
|
2
|
0
|
0
|
0
|
2
|
0
|
0
|
0
|
135.64
|
1755 |
60
|
0.031
|
1292
|
| Chip 1 |
A
|
4
|
0
|
0
|
3
|
0
|
0
|
0
|
1
|
1
|
0
|
0
|
137.76
|
1752 |
57
|
0.035
|
1081
|
| Chip 2 |
A
|
2
|
0
|
0
|
1
|
0
|
0
|
0
|
1
|
0
|
0
|
1
|
142.33
|
1755 |
58
|
0.029
|
1012
|
| Chip 3 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
147.21
|
1753 |
55
|
0.028
|
1166
|
| Chip 4 |
A
|
5
|
0
|
0
|
1
|
0
|
0
|
0
|
4
|
0
|
0
|
2
|
182.83
|
1759 |
69
|
0.049
|
1288
|
| Chip 5 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
156.14
|
1756 |
60
|
0.032
|
1326
|
| Chip 6 |
A
|
6
|
1
|
0
|
2
|
0
|
0
|
0
|
3
|
1
|
0
|
1
|
145.30
|
1757 |
57
|
0.030
|
1105
|
| Chip 7 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
145.90
|
1753 |
55
|
0.037
|
1128
|
| Chip 8 |
A
|
2
|
0
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
147.51
|
1758 |
62
|
0.035
|
1532
|
| Chip 9 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
148.13
|
1758 |
60
|
0.038
|
1084
|
| Chip 10 |
A
|
5
|
0
|
0
|
1
|
0
|
0
|
0
|
3
|
1
|
0
|
2
|
146.40
|
1754 |
57
|
0.047
|
1404
|
| Chip 11 |
A
|
3
|
1
|
0
|
1
|
0
|
0
|
0
|
1
|
0
|
0
|
2
|
148.36
|
1757 |
64
|
0.037
|
1152
|
| Chip 12 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
2
|
130.82
|
1742 |
58
|
0.033
|
1346
|
| Chip 13 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
131.81
|
1740 |
52
|
0.027
|
968
|
| Chip 14 |
A
|
3
|
0
|
0
|
3
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
133.31
|
1754 |
55
|
0.034
|
1253
|
| Chip 15 |
A
|
4
|
2
|
0
|
2
|
1
|
0
|
0
|
0
|
1
|
0
|
2
|
145.52
|
1758 |
57
|
0.035
|
1124
|
TBM
| nTBMs | n | 1 | |
| TBMType | Type | tbm08c | |
| Core0a_basea | Core 0a base a | 0xf6 | |
| Core0a_basee | Core 0a base e | 0x30 | |
| Core0b_basea | Core 0b base a | 0xf6 | |
| Core0b_basee | Core 0b base e | 0x00 | |
| RocDelay_Ch0 | Roc Delay Ch0 | 6 | |
| RocDelay_Ch1 | Roc Delay Ch1 | 6 | |
| RocDelay_Ch2 | Roc Delay Ch2 | 6 | |
| RocDelay_Ch3 | Roc Delay Ch3 | 6 | |
| Phase400 | Phase 400 | 4 | |
| Phase160 | Phase 160 | 1 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 12 | |
| nWarnings | # Warnings | 12 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 24 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 10 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 12 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
