Test Date: 2015-07-27 09:56
Analysis date: 2015-10-28 14:47
Analysis date: 2015-10-28 14:47
M3015 ModuleFulltest_m20_2
Summary 1
| Module | Module | M3015 | |
| Grade | Grade | A | |
| ElectricalGrade | Electrical Grade | A | |
| IVGrade | IV Grade | A | |
| ManualGrade | Manual Grade | None | |
| PixelDefects | Pixel Defects - A/B/C | 37 - 16/0/0 | |
| DeadPixels | Dead Pixels | 4 | |
| AddressProblems | Address Problems | 0 | |
| ThresholdDefects | Threshold Defects | 11 | |
| MaskDefects | Mask Defects | 0 | |
| DeadBumps | Dead Bumps | 17 | |
| NoisyPixels | Noise Defects | 0 | |
| TrimProblems | Trim Problems | 1 | |
| PHGainDefects | PH Gain Defects | 9 | |
| PHPedestalDefects | PH Pedestal Defects | 0 | |
| PHPar1Defects | PH Parameter1 Defects | 10 |
Summary 2
| TestCenter | Test Center | CERN | |
| TestDate | Test Date | 2015-07-27 | |
| TestTime | Test Time | 09:56 | |
| TestDuration | Test Duration | 1:01:14 | |
| TempC | Temparature | -20 | °C |
| TrimPHCal | Trim / phCal | yes / yes | |
| TermCycl | Term. Cycl. | yes | |
| TBM1 | TBM1 | ok, 0x30 0xf6 | |
| TBM2 | TBM2 | ok, 0x00 0xf6 | |
| PxarVersion | pXar | v2.2.5+67 g3b1c276 | |
| ModuleIa | Module Ia | 396.3 | mA |
Summary 3
| Noise | Noise | 136.75 | e |
| NoiseROCs | Noise grades | 16/0/0 | |
| VcalThrWidth | Vcal Thr. Width | 56.81 | e |
| VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
| RelGainWidth | Rel. Gain Width | 0.04 | % |
| RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
| PedestalSpread | Pedestal Spread | 1119.81 | e |
| PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
| Parameter1 | Parameter1 | 0.75 | |
| Parameter1ROCs | Par1 grades | 16/0/0 | |
| CurrentAtVoltage150V | I_rec(150 V) @ 17°C | 0.34 | μA |
| CurrentAtVoltage150V_ORIG | I_orig(150V) @ -20.0 °C | 0.01 | μA |
| CurrentVariation | I(150 V) / I(100 V) | 1.19 |
IVCurve
| CurrentAtVoltage150V | I_orig(150V) @ -20.0 °C | 0.01 | μA |
| Variation | I(150 V) / I(100 V) | 1.19 | |
| recalculatedCurrentAtVoltage150V | I_rec(150 V) @ 17°C | 0.34 | μA |
| recalculatedCurrentVariation | I_rec(150 V) / I_rec(100 V) | 1.19 |
Digital Current
| Duration | Duration | 1:01:14 | |
| MinCurrent | min. Current | 0.432 | A |
| MaxCurrent | max. Current | 0.473 | A |
Analog Current
| Duration | Duration | 1:01:14 | |
| MinCurrent | min. Current | 0.359 | A |
| MaxCurrent | max. Current | 0.4 | A |
| ModuleIa | Module Ia | 396.3 | mA |
Temperature
| Temperature | Temp. while test | -20.00 +/- 0.02 | °C |
| Duration | Duration of test | 0:05:20 |
Summary ROCs
| ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Chip 0 |
A
|
2
|
0
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
128.65
|
1760 |
57
|
0.031
|
1208
|
| Chip 1 |
A
|
3
|
0
|
0
|
3
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
133.91
|
1756 |
56
|
0.031
|
993
|
| Chip 2 |
A
|
2
|
0
|
0
|
1
|
0
|
0
|
0
|
1
|
0
|
0
|
1
|
135.53
|
1756 |
56
|
0.031
|
964
|
| Chip 3 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
130.19
|
1753 |
54
|
0.029
|
1072
|
| Chip 4 |
A
|
3
|
0
|
0
|
1
|
0
|
0
|
0
|
2
|
2
|
0
|
1
|
169.85
|
1760 |
62
|
0.049
|
1163
|
| Chip 5 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
148.15
|
1758 |
62
|
0.035
|
1251
|
| Chip 6 |
A
|
3
|
1
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
139.71
|
1755 |
56
|
0.026
|
998
|
| Chip 7 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
125.68
|
1754 |
54
|
0.038
|
1025
|
| Chip 8 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
1
|
0
|
1
|
143.50
|
1755 |
64
|
0.036
|
1486
|
| Chip 9 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
134.53
|
1754 |
57
|
0.038
|
1015
|
| Chip 10 |
A
|
4
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
4
|
0
|
0
|
135.35
|
1756 |
56
|
0.050
|
1322
|
| Chip 11 |
A
|
6
|
1
|
0
|
2
|
0
|
0
|
0
|
3
|
1
|
0
|
2
|
142.57
|
1755 |
60
|
0.037
|
1071
|
| Chip 12 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
0
|
0
|
2
|
125.11
|
1752 |
56
|
0.033
|
1231
|
| Chip 13 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
123.90
|
1753 |
53
|
0.031
|
908
|
| Chip 14 |
A
|
3
|
0
|
0
|
2
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
135.73
|
1749 |
54
|
0.034
|
1153
|
| Chip 15 |
A
|
5
|
2
|
0
|
2
|
1
|
0
|
0
|
1
|
1
|
0
|
2
|
135.57
|
1752 |
53
|
0.038
|
1056
|
TBM
| nTBMs | n | 1 | |
| TBMType | Type | tbm08c | |
| Core0a_basea | Core 0a base a | 0xf6 | |
| Core0a_basee | Core 0a base e | 0x30 | |
| Core0b_basea | Core 0b base a | 0xf6 | |
| Core0b_basee | Core 0b base e | 0x00 | |
| RocDelay_Ch0 | Roc Delay Ch0 | 6 | |
| RocDelay_Ch1 | Roc Delay Ch1 | 6 | |
| RocDelay_Ch2 | Roc Delay Ch2 | 6 | |
| RocDelay_Ch3 | Roc Delay Ch3 | 6 | |
| Phase400 | Phase 400 | 4 | |
| Phase160 | Phase 160 | 1 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 31 | |
| nWarnings | # Warnings | 208 | |
| channel_0_count | Channel 0 | 200 | |
| channel_1_count | Channel 1 | 39 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 11 | |
| message_eventid_count | Event ID mismatch | 20 | |
| message_readback_count | Readback start marker | 208 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
GradingParameters
| ModifiedGrading | Modified Grading | False |
MoReWeb-v0.6.7-17-g62372b6
on branch psi46master
