Module | Module | M3015 | |
Grade | Grade | A | |
ElectricalGrade | Electrical Grade | A | |
IVGrade | IV Grade | A | |
ManualGrade | Manual Grade | None | |
PixelDefects | Pixel Defects - A/B/C | 42 - 16/0/0 | |
DeadPixels | Dead Pixels | 4 | |
AddressProblems | Address Problems | 0 | |
ThresholdDefects | Threshold Defects | 18 | |
MaskDefects | Mask Defects | 0 | |
DeadBumps | Dead Bumps | 19 | |
NoisyPixels | Noise Defects | 1 | |
TrimProblems | Trim Problems | 1 | |
PHGainDefects | PH Gain Defects | 4 | |
PHPedestalDefects | PH Pedestal Defects | 0 | |
PHPar1Defects | PH Parameter1 Defects | 12 |
TestCenter | Test Center | CERN | |
TestDate | Test Date | 2015-07-27 | |
TestTime | Test Time | 09:56 | |
TestDuration | Test Duration | 1:01:52 | |
TempC | Temparature | -20 | °C |
TrimPHCal | Trim / phCal | yes / yes | |
TermCycl | Term. Cycl. | yes | |
TBM1 | TBM1 | ok, 0x30 0xf6 | |
TBM2 | TBM2 | ok, 0x00 0xf6 | |
PxarVersion | pXar | v2.2.5+67 g3b1c276 | |
ModuleIa | Module Ia | 394.7 | mA |
Noise | Noise | 136.93 | e |
NoiseROCs | Noise grades | 16/0/0 | |
VcalThrWidth | Vcal Thr. Width | 56.34 | e |
VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
RelGainWidth | Rel. Gain Width | 0.04 | % |
RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
PedestalSpread | Pedestal Spread | 1118.59 | e |
PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
Parameter1 | Parameter1 | 0.75 | |
Parameter1ROCs | Par1 grades | 16/0/0 | |
CurrentAtVoltage150V | I_rec(150 V) @ 17°C | 0.33 | μA |
CurrentAtVoltage150V_ORIG | I_orig(150V) @ -20.0 °C | 0.01 | μA |
CurrentVariation | I(150 V) / I(100 V) | 1.17 |
CurrentAtVoltage150V | I_orig(150V) @ -20.0 °C | 0.01 | μA |
Variation | I(150 V) / I(100 V) | 1.17 | |
recalculatedCurrentAtVoltage150V | I_rec(150 V) @ 17°C | 0.33 | μA |
recalculatedCurrentVariation | I_rec(150 V) / I_rec(100 V) | 1.17 | |
CurrentRatio100V | I(+17C)/I(-20C) 100V | 50.63 | |
CurrentRatio150V | I(+17C)/I(-20C) 150V | 45.33 |
Duration | Duration | 1:01:52 | |
MinCurrent | min. Current | 0.432 | A |
MaxCurrent | max. Current | 0.472 | A |
Duration | Duration | 1:01:52 | |
MinCurrent | min. Current | 0.359 | A |
MaxCurrent | max. Current | 0.398 | A |
ModuleIa | Module Ia | 394.7 | mA |
Temperature | Temp. while test | -20.00 +/- 0.01 | °C |
Duration | Duration of test | 0:05:22 |
ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Chip 0 |
A
|
3
|
0
|
0
|
2
|
0
|
0
|
0
|
1
|
0
|
0
|
1
|
128.66
|
1760 |
57
|
0.031
|
1219
|
Chip 1 |
A
|
4
|
0
|
0
|
3
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
134.32
|
1757 |
56
|
0.031
|
990
|
Chip 2 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
134.35
|
1754 |
55
|
0.031
|
954
|
Chip 3 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
130.22
|
1752 |
55
|
0.029
|
1074
|
Chip 4 |
A
|
4
|
0
|
0
|
1
|
0
|
0
|
1
|
2
|
0
|
0
|
0
|
168.51
|
1755 |
64
|
0.048
|
1164
|
Chip 5 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
1
|
0
|
0
|
148.44
|
1755 |
60
|
0.037
|
1263
|
Chip 6 |
A
|
5
|
1
|
0
|
2
|
0
|
0
|
0
|
2
|
1
|
0
|
2
|
140.43
|
1752 |
58
|
0.029
|
1004
|
Chip 7 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
128.19
|
1750 |
49
|
0.036
|
1025
|
Chip 8 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
143.00
|
1755 |
60
|
0.037
|
1459
|
Chip 9 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
135.43
|
1754 |
56
|
0.037
|
1020
|
Chip 10 |
A
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
1
|
0
|
2
|
136.84
|
1752 |
56
|
0.050
|
1300
|
Chip 11 |
A
|
6
|
1
|
0
|
2
|
0
|
0
|
0
|
3
|
0
|
0
|
3
|
142.70
|
1754 |
60
|
0.037
|
1076
|
Chip 12 |
A
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
0
|
0
|
1
|
124.95
|
1753 |
56
|
0.033
|
1238
|
Chip 13 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
124.12
|
1752 |
51
|
0.028
|
899
|
Chip 14 |
A
|
4
|
0
|
0
|
3
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
135.33
|
1754 |
55
|
0.034
|
1153
|
Chip 15 |
A
|
6
|
2
|
0
|
2
|
1
|
0
|
0
|
2
|
1
|
0
|
3
|
135.45
|
1756 |
55
|
0.035
|
1057
|
nTBMs | n | 1 | |
TBMType | Type | tbm08c | |
Core0a_basea | Core 0a base a | 0xf6 | |
Core0a_basee | Core 0a base e | 0x30 | |
Core0b_basea | Core 0b base a | 0xf6 | |
Core0b_basee | Core 0b base e | 0x00 | |
RocDelay_Ch0 | Roc Delay Ch0 | 6 | |
RocDelay_Ch1 | Roc Delay Ch1 | 6 | |
RocDelay_Ch2 | Roc Delay Ch2 | 6 | |
RocDelay_Ch3 | Roc Delay Ch3 | 6 | |
Phase400 | Phase 400 | 4 | |
Phase160 | Phase 160 | 1 |
nCriticals | # Criticals | 1 | |
nErrors | # Errors | 35 | |
nWarnings | # Warnings | 233 | |
channel_0_count | Channel 0 | 226 | |
channel_1_count | Channel 1 | 42 | |
channel_2_count | Channel 2 | 0 | |
channel_3_count | Channel 3 | 0 | |
message_tokenchain_count | Token Chain Length | 11 | |
message_eventid_count | Event ID mismatch | 24 | |
message_readback_count | Readback start marker | 233 | |
message_notokenpass_count | has NoTokenPass | 0 | |
message_datasize_count | Data size criticals | 0 | |
message_missingevents_count | Missing Event criticals | 1 | |
message_usbtimeout_count | USB criticals | 0 | |
message_deser400_count | DESER400 failure | 0 | |
message_daqerror_count | DAQ error | 0 |
ModifiedGrading | Modified Grading | False |
