Test Date: 2016-10-11 09:45
Analysis date: 2016-10-11 11:28
Analysis date: 2016-10-11 11:28
M2359 XRayHRQualification
Summary
| Module | Module | M2359 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 19 | |
| BumpBondingDefects | Bump Bonding Defects | 19 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.20 | % |
| Noise | Mean Noise | 161 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
9 | 0 | 99.86 | 99.22 | 0.46 | 22.8 | 69.2 | 9 | 0/0 | 0 | 1956 | 156 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.87 | 99.21 | 0.43 | 20.8 | 64.9 | 0 | 0/0 | 0 | 1945 | 158 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.22 | 1.45 | 19.3 | 60.2 | 0 | 0/0 | 0 | 1926 | 162 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.13 | 0.61 | 33.5 | 100.7 | 0 | 0/0 | 0 | 2027 | 156 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.33 | 0.45 | 40.0 | 120.2 | 0 | 0/0 | 0 | 2071 | 171 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.28 | 0.78 | 46.1 | 135.1 | 0 | 0/0 | 0 | 2086 | 158 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.84 | 99.09 | 0.67 | 39.6 | 116.7 | 0 | 0/0 | 0 | 2047 | 155 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.31 | 0.45 | 42.2 | 125.0 | 0 | 0/0 | 0 | 2062 | 160 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.30 | 0.7 | 46.3 | 137.1 | 0 | 0/0 | 0 | 2111 | 162 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.84 | 98.99 | 1.12 | 48.8 | 143.8 | 0 | 0/0 | 0 | 2117 | 169 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.88 | 99.31 | 0.43 | 40.7 | 121.6 | 0 | 0/0 | 0 | 2052 | 150 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.30 | 0.52 | 39.5 | 117.5 | 0 | 0/0 | 0 | 2049 | 158 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.18 | 0.64 | 39.2 | 116.5 | 0 | 0/0 | 0 | 2057 | 166 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.21 | 0.56 | 24.2 | 73.9 | 0 | 0/0 | 0 | 1974 | 166 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.86 | 99.22 | 0.47 | 25.6 | 77.7 | 0 | 0/0 | 0 | 1987 | 167 | 0 |
|
Chip 15
|
A
|
10 | 0 | 99.80 | 98.93 | 0.6 | 26.3 | 79.2 | 10 | 0/0 | 0 | 1962 | 165 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-11 | |
| TestTime | Test Time | 09:45 | |
| TestDuration | Duration | 1:16:51 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 9 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 1 |
MoReWeb-v1.0.4-4-g297680c on branch psi46master
