Test Date: 2016-10-11 09:45
Analysis date: 2016-10-11 11:21
Analysis date: 2016-10-11 11:21
M2356 XRayHRQualification
Summary
| Module | Module | M2356 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.14 | % |
| Noise | Mean Noise | 171 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 0 | 99.82 | 98.94 | 0.7 | 26.2 | 79.1 | 2 | 0/0 | 0 | 1957 | 180 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 98.92 | 0.56 | 25.8 | 79.0 | 0 | 0/0 | 0 | 1950 | 182 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 98.99 | 0.63 | 21.0 | 65.5 | 0 | 0/0 | 0 | 1924 | 160 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.29 | 0.65 | 40.7 | 121.2 | 0 | 0/0 | 0 | 2102 | 174 | 0 |
|
Chip 4
|
A
|
1 | 0 | 99.86 | 99.30 | 0.45 | 40.1 | 119.6 | 1 | 0/0 | 0 | 2077 | 173 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.85 | 99.25 | 0.7 | 51.0 | 149.8 | 0 | 0/0 | 0 | 2143 | 176 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.87 | 99.31 | 0.61 | 47.3 | 139.5 | 0 | 0/0 | 0 | 2119 | 176 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.25 | 0.86 | 46.8 | 137.3 | 0 | 0/0 | 0 | 2124 | 164 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.83 | 99.00 | 0.88 | 43.0 | 127.3 | 0 | 0/0 | 0 | 2088 | 167 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.30 | 0.59 | 42.4 | 126.6 | 0 | 0/0 | 0 | 2081 | 173 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.89 | 99.30 | 0.51 | 38.6 | 114.7 | 0 | 0/0 | 0 | 2037 | 170 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.82 | 98.96 | 0.65 | 35.8 | 107.9 | 0 | 0/0 | 0 | 2056 | 173 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.82 | 98.99 | 0.57 | 33.2 | 100.2 | 0 | 0/0 | 0 | 2029 | 168 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.85 | 99.23 | 0.61 | 19.2 | 60.1 | 0 | 0/0 | 0 | 1959 | 165 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.84 | 99.24 | 0.43 | 22.3 | 68.7 | 0 | 0/0 | 0 | 1957 | 166 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 98.91 | 0.45 | 21.6 | 65.9 | 0 | 0/0 | 0 | 1951 | 168 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-10-11 | |
| TestTime | Test Time | 09:45 | |
| TestDuration | Duration | 1:16:51 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 486 | |
| nWarnings | # Warnings | 12 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 5 | |
| channel_3_count | Channel 3 | 58 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_tokenchain_count | Token Chain Length | 52 | |
| message_readback_count | Readback start marker | 10 |
MoReWeb-v1.0.4-4-g297680c on branch psi46master
