Test Date: 2016-09-27 17:30
Analysis date: 2016-09-27 19:28
Analysis date: 2016-09-27 19:28
M2345 XRayHRQualification
Summary
| Module | Module | M2345 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.18 | % |
| Noise | Mean Noise | 169 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.82 | 98.95 | 0.69 | 31.1 | 92.1 | 0 | 0/0 | 0 | 2017 | 172 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 99.00 | 0.62 | 31.7 | 95.0 | 0 | 0/0 | 0 | 2007 | 172 | 0 |
|
Chip 2
|
A
|
1 | 0 | 99.78 | 98.95 | 0.75 | 28.9 | 87.8 | 0 | 0/0 | 0 | 1992 | 178 | 1 |
|
Chip 3
|
A
|
0 | 0 | 99.87 | 99.27 | 0.76 | 49.6 | 144.6 | 0 | 0/0 | 0 | 2132 | 165 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.85 | 99.21 | 0.84 | 52.9 | 155.0 | 0 | 0/0 | 0 | 2137 | 171 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.30 | 0.5 | 61.8 | 176.8 | 0 | 0/0 | 0 | 2191 | 159 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.26 | 1.27 | 61.8 | 179.1 | 0 | 0/0 | 0 | 2201 | 164 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.24 | 0.91 | 63.6 | 182.8 | 0 | 0/0 | 0 | 2214 | 157 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.87 | 99.28 | 1.16 | 69.1 | 200.2 | 0 | 0/0 | 0 | 2226 | 172 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.25 | 0.59 | 64.5 | 186.9 | 0 | 0/0 | 0 | 2202 | 164 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.84 | 99.30 | 0.7 | 69.4 | 199.7 | 0 | 0/0 | 0 | 2233 | 174 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.22 | 0.95 | 58.4 | 171.2 | 0 | 0/0 | 0 | 2184 | 178 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.25 | 0.84 | 52.1 | 151.9 | 0 | 0/0 | 0 | 2140 | 171 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.84 | 98.94 | 0.62 | 27.4 | 83.6 | 0 | 0/0 | 0 | 1994 | 165 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.25 | 0.51 | 33.2 | 99.4 | 0 | 0/0 | 0 | 2027 | 176 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.87 | 99.26 | 0.59 | 31.6 | 93.4 | 0 | 0/0 | 0 | 2012 | 170 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-27 | |
| TestTime | Test Time | 17:30 | |
| TestDuration | Duration | 1:17:22 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 27 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 2 | |
| channel_2_count | Channel 2 | 1 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 3 | |
| message_readback_count | Readback start marker | 1 |
MoReWeb-v1.0.4-4-g297680c on branch psi46master
