Test Date: 2016-09-22 14:30
Analysis date: 2016-09-22 16:16
Analysis date: 2016-09-22 16:16
M2344 XRayHRQualification
Summary
| Module | Module | M2344 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 28 | |
| BumpBondingDefects | Bump Bonding Defects | 28 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.85/99.16 | % |
| Noise | Mean Noise | 165 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
10 | 0 | 99.86 | 99.24 | 0.77 | 28.9 | 87.4 | 10 | 0/0 | 0 | 1982 | 172 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.01 | 0.47 | 27.2 | 84.0 | 0 | 0/0 | 0 | 1980 | 162 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 98.90 | 0.88 | 26.0 | 80.1 | 0 | 0/0 | 0 | 1956 | 167 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.85 | 99.16 | 0.78 | 46.6 | 138.4 | 1 | 0/0 | 0 | 2126 | 170 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.82 | 98.96 | 0.73 | 47.9 | 143.1 | 0 | 0/0 | 0 | 2107 | 163 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.26 | 1.11 | 60.4 | 174.7 | 0 | 0/0 | 0 | 2198 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.86 | 99.00 | 6.69 | 62.8 | 184.2 | 0 | 0/0 | 0 | 2209 | 172 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.85 | 99.25 | 1.06 | 64.5 | 188.5 | 0 | 0/0 | 0 | 2225 | 170 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.86 | 99.32 | 0.6 | 64.6 | 189.7 | 0 | 0/0 | 0 | 2201 | 167 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.33 | 0.68 | 53.6 | 158.1 | 0 | 0/0 | 0 | 2129 | 160 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.30 | 0.93 | 64.2 | 185.5 | 0 | 0/0 | 0 | 2228 | 162 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.87 | 99.26 | 0.69 | 48.7 | 145.1 | 0 | 0/0 | 0 | 2120 | 159 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.29 | 0.85 | 49.1 | 146.6 | 0 | 0/0 | 0 | 2130 | 169 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.82 | 98.92 | 0.75 | 26.8 | 82.6 | 1 | 0/0 | 0 | 2000 | 160 | 0 |
|
Chip 14
|
A
|
1 | 0 | 99.86 | 99.18 | 0.57 | 29.9 | 91.6 | 1 | 0/0 | 0 | 1984 | 163 | 0 |
|
Chip 15
|
A
|
15 | 0 | 99.86 | 99.22 | 0.56 | 29.4 | 89.0 | 15 | 0/0 | 0 | 1999 | 168 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-22 | |
| TestTime | Test Time | 14:30 | |
| TestDuration | Duration | 1:11:44 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
