Test Date: 2016-09-22 14:30
Analysis date: 2016-09-22 16:14
Analysis date: 2016-09-22 16:14
M2342 XRayHRQualification
Summary
| Module | Module | M2342 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 0 | |
| BumpBondingDefects | Bump Bonding Defects | 0 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.23 | % |
| Noise | Mean Noise | 159 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.84 | 99.03 | 0.87 | 28.8 | 87.6 | 0 | 0/0 | 0 | 1994 | 166 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.16 | 0.51 | 31.6 | 96.5 | 0 | 0/0 | 0 | 2008 | 167 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.84 | 99.27 | 0.68 | 25.9 | 81.0 | 0 | 0/0 | 0 | 1975 | 163 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.85 | 99.24 | 0.56 | 45.6 | 136.5 | 0 | 0/0 | 0 | 2104 | 155 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.87 | 99.31 | 0.49 | 50.5 | 150.8 | 0 | 0/0 | 0 | 2136 | 165 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.24 | 1.13 | 58.4 | 169.8 | 0 | 0/0 | 0 | 2182 | 153 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.36 | 0.62 | 62.2 | 182.9 | 0 | 0/0 | 0 | 2220 | 163 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.89 | 99.39 | 0.71 | 65.0 | 191.4 | 0 | 0/0 | 0 | 2231 | 164 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.89 | 99.34 | 0.64 | 58.8 | 173.1 | 0 | 0/0 | 0 | 2201 | 155 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.87 | 99.33 | 0.63 | 56.1 | 164.4 | 0 | 0/0 | 0 | 2166 | 153 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.31 | 0.56 | 61.3 | 176.7 | 0 | 0/0 | 0 | 2201 | 159 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.88 | 99.29 | 0.65 | 47.1 | 140.4 | 0 | 0/0 | 0 | 2119 | 156 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.87 | 99.29 | 0.58 | 47.9 | 142.8 | 0 | 0/0 | 0 | 2124 | 158 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.83 | 99.03 | 0.8 | 26.6 | 82.0 | 0 | 0/0 | 0 | 1994 | 155 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 99.16 | 0.86 | 26.3 | 81.6 | 0 | 0/0 | 0 | 1980 | 149 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.85 | 98.95 | 0.62 | 27.4 | 83.5 | 0 | 0/0 | 0 | 1992 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-22 | |
| TestTime | Test Time | 14:30 | |
| TestDuration | Duration | 1:11:44 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
