Test Date: 2016-09-27 09:42
Analysis date: 2016-09-27 11:18
Analysis date: 2016-09-27 11:18
M2327 XRayHRQualification
Summary
| Module | Module | M2327 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.22 | % |
| Noise | Mean Noise | 167 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 0 | 99.86 | 99.25 | 0.59 | 24.3 | 73.6 | 1 | 0/0 | 0 | 1970 | 177 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.84 | 98.95 | 0.72 | 24.8 | 75.6 | 0 | 0/0 | 0 | 1980 | 172 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.83 | 98.96 | 0.36 | 19.3 | 60.2 | 0 | 0/0 | 0 | 1914 | 158 | 0 |
|
Chip 3
|
A
|
0 | 0 | 99.88 | 99.27 | 0.45 | 38.5 | 114.7 | 0 | 0/0 | 0 | 2075 | 167 | 0 |
|
Chip 4
|
A
|
0 | 0 | 99.86 | 99.28 | 0.63 | 40.6 | 121.6 | 0 | 0/0 | 0 | 2063 | 177 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.87 | 99.35 | 0.58 | 44.7 | 131.5 | 0 | 0/0 | 0 | 2106 | 161 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.32 | 0.51 | 43.8 | 130.1 | 0 | 0/0 | 0 | 2097 | 169 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.86 | 99.25 | 0.71 | 49.5 | 146.3 | 0 | 0/0 | 0 | 2121 | 172 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 99.24 | 0.85 | 41.0 | 121.2 | 0 | 0/0 | 0 | 2074 | 166 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.86 | 99.29 | 0.61 | 42.8 | 126.7 | 0 | 0/0 | 0 | 2086 | 173 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.30 | 0.45 | 40.5 | 119.4 | 0 | 0/0 | 0 | 2067 | 160 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.86 | 99.26 | 0.58 | 37.0 | 110.9 | 0 | 0/0 | 0 | 2058 | 166 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.14 | 0.52 | 34.0 | 102.0 | 0 | 0/0 | 0 | 2053 | 170 | 0 |
|
Chip 13
|
A
|
0 | 0 | 99.88 | 99.39 | 0.3 | 17.4 | 54.6 | 0 | 0/0 | 0 | 1927 | 155 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.87 | 99.24 | 0.47 | 19.4 | 60.6 | 0 | 0/0 | 0 | 1929 | 153 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 98.99 | 0.58 | 21.1 | 64.3 | 0 | 0/0 | 0 | 1941 | 169 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-27 | |
| TestTime | Test Time | 09:42 | |
| TestDuration | Duration | 1:16:47 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
