Test Date: 2016-09-26 10:58
Analysis date: 2016-09-26 13:30
Analysis date: 2016-09-26 13:30
M2325 XRayHRQualification
Summary
| Module | Module | M2325 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 2 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 1 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 50/120 | 99.86/99.17 | % |
| Noise | Mean Noise | 162 | e- |
Summary ROCs
| ROC | Grade | Def | DC | Eff 50 | Eff 120 | Eff chi2 | Rate "50" | Rate "150" | BB def | R/O | Unif. | Thr [e-] "100" | Noise "100" | Noisy pix |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 0 | 99.88 | 99.26 | 0.44 | 23.7 | 70.6 | 0 | 0/0 | 0 | 1965 | 165 | 0 |
|
Chip 1
|
A
|
0 | 0 | 99.85 | 99.21 | 1.05 | 23.6 | 71.4 | 0 | 0/0 | 0 | 1964 | 157 | 0 |
|
Chip 2
|
A
|
0 | 0 | 99.86 | 99.23 | 0.3 | 22.2 | 67.8 | 0 | 0/0 | 0 | 1937 | 161 | 0 |
|
Chip 3
|
A
|
1 | 0 | 99.87 | 99.29 | 0.38 | 37.6 | 110.6 | 0 | 0/0 | 0 | 2026 | 159 | 1 |
|
Chip 4
|
A
|
0 | 0 | 99.84 | 99.16 | 1.15 | 42.6 | 124.7 | 0 | 0/0 | 0 | 2096 | 161 | 0 |
|
Chip 5
|
A
|
0 | 0 | 99.88 | 99.28 | 0.63 | 46.2 | 133.6 | 0 | 0/0 | 0 | 2096 | 155 | 0 |
|
Chip 6
|
A
|
0 | 0 | 99.88 | 99.32 | 0.36 | 48.8 | 142.8 | 0 | 0/0 | 0 | 2128 | 164 | 0 |
|
Chip 7
|
A
|
0 | 0 | 99.88 | 99.30 | 0.78 | 54.8 | 158.6 | 0 | 0/0 | 0 | 2176 | 165 | 0 |
|
Chip 8
|
A
|
0 | 0 | 99.85 | 99.18 | 1.11 | 50.5 | 147.2 | 0 | 0/0 | 0 | 2164 | 167 | 0 |
|
Chip 9
|
A
|
0 | 0 | 99.85 | 99.00 | 0.71 | 40.1 | 118.2 | 0 | 0/0 | 0 | 2086 | 161 | 0 |
|
Chip 10
|
A
|
0 | 0 | 99.87 | 99.27 | 0.6 | 45.9 | 133.1 | 0 | 0/0 | 0 | 2104 | 166 | 0 |
|
Chip 11
|
A
|
0 | 0 | 99.83 | 98.98 | 0.8 | 36.0 | 106.5 | 0 | 0/0 | 0 | 2035 | 152 | 0 |
|
Chip 12
|
A
|
0 | 0 | 99.86 | 99.14 | 0.62 | 33.5 | 100.0 | 0 | 0/0 | 0 | 2031 | 162 | 0 |
|
Chip 13
|
A
|
1 | 0 | 99.86 | 99.30 | 0.5 | 20.2 | 62.0 | 1 | 0/0 | 0 | 1943 | 168 | 0 |
|
Chip 14
|
A
|
0 | 0 | 99.85 | 98.95 | 0.52 | 20.0 | 61.6 | 0 | 0/0 | 0 | 1949 | 157 | 0 |
|
Chip 15
|
A
|
0 | 0 | 99.84 | 98.91 | 0.4 | 19.9 | 60.5 | 0 | 0/0 | 0 | 1924 | 163 | 0 |
Setup
| TestCenter | Test Center | ETHZ | |
| TestDate | Test Date | 2016-09-26 | |
| TestTime | Test Time | 10:58 | |
| TestDuration | Duration | 1:16:48 | |
| pXar | pXar version | v2.7.6+55~gafdbfd9 | |
| DTB_FW | DTB FW | 4.7 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 |
MoReWeb-v1.0.2-10-gbc52a17 on branch psi46master
